3. To view images from this input, press the VGA button on the remote control. To select an
appropriate audio source, see page 27 "Sound Menu" for details.
*1 D-Sub (15-pin) cable
*2 Audio cable
• The audio cable is not supplied and should be purchased separately.
Connecting the Digital Inputs
1. Connect the HDMI output jack of a computer or A/V device (such as a VCR or DVD
player) to the HDMI Input jack on the machine using an HDMI cable. If the device has a
DisplayPort output jack, connect it to the DisplayPort Input jack on the machine using a
DisplayPort cable.
If the device has a DVI-D output jack, connect it to the DVI-D Input jack on the machine
using a DVI cable.
2. If the DVI-D connection is used, connect the audio output jack of the device to the Audio
Input (VGA/DVI) jack on the machine using a suitable audio cable. This audio connection
is not required for the HDMI or DisplayPort connection.
2. Connection
12
