Function Length
Set Command Get Command
Value Range
(ASCII Bytes)
Remark
Command
Type
Command
Code
(Hex)
Command
Type
Command
Code
(Hex)
Power 8 73 21 - - 000: Standby
Video Source 8 73 22 67 6A 000: VGA If the PIP (Picture in Picture) or PBP (Picture by
Picture) function is enabled, the returned value is the
source at the active window.
001: HDMI
002: Computer In This is valid if the OPS (Open Pluggable Specification)
controller is connected to the machine.
006: DVI
007: DisplayPort
Picture Menu
Picture Mode 8 73 81 67 B1 000: Standard
001: Vivid
002: Cinema
003: Custom
004: Low Blue Light
Backlight 8 73 84 67 B4 000–100
Contrast 8 73 23 67 61 000–100
Brightness 8 73 24 67 62 000–100
Chroma (Color) 8 73 82 67 B2 000–100
Phase (Tint) 8 73 83 67 B3 000–100
Sharpness 8 73 25 67 63 000–010
Color Temp 8 73 88 67 B6 000: Cool
001: Neutral
002: Warm
003: Custom
004: Low Blue Light
Picture Reset 8 73 26 - - Whatever value can be specified.
Sound Menu
Sound Mode 8 73 33 67 65 000: Dynamic
001: Standard
002: Custom
Treble 8 73 37 67 37 000–010 OSD value = RS232 value-5
Bass 8 73 38 67 38 000–010 OSD value = RS232 value-5
Balance 8 73 39 67 39 000–066 OSD value = RS232 value-33
Volume 8 73 35 67 66 000–100
Mute 8 73 36 67 67 000: Off
001: On
Speaker 8 73 89 67 B9 000: Internal
001: External
Audio Source 8 73 88 67 88 000: Audio In
002: HDMI
001: Computer In This is valid if the OPS (Open Pluggable Specification)
controller is connected to the machine.
004: DisplayPort
100: Auto
Sound Reset 8 73 3B - - Whatever value can be specified.
Screen Menu
PAP Enable 8 73 8A 67 BA 000: Off
001: PIP
002: PBP
PAP Sub source 8 73 8B 67 BB 000: VGA
001: HDMI
001: Computer In This is valid if the OPS (Open Pluggable Specification)
controller is connected to the machine.
006: DVI
007: DisplayPort
Set and Get Commands Table
In the table below, hyphens "-" indicate items that are not supported.
