Smart Organizing Monitor
SM 5-1 M154/M155/M174/M175/A0A7/M287/M0BB
Service Tables
5. SERVICE TABLES
5.1 SMART ORGANIZING MONITOR
5.1.1 OVERVIEW
SOM (Smart Organizing Monitor) is a utility which can check the status of a printer and set up a
printer from a PC. This utility is executed from a printer driver.
5.1.2 PRINTER DRIVER INSTALLATION (USB CONNECTION)
1. Close all applications currently running.
2. Check the following:
 The printer's USB cable is disconnected
 The printer's main power switch is turned off
3. Insert the CD-ROM into the CD-ROM drive.
The installer starts.
4. Select the interface language, and then click [OK].
5. Click [DDST Printer Driver] or [PCL 6 Printer Driver].
The software license agreement appears.
6. After reading the agreement, click [I accept the agreement.], and then click [Next >].
7. In the [Method to install printer driver] dialog box, clear the [Search for network printers.]
check box, select the [Connect a printer using a USB cable.] check box, and then click [Next
>].
8. Select this printer, and then click [Next >].
A message appears, asking you to check that the USB cable is not connected and that the
printer's main power switch is turned to off.
9. Check the USB cable and the printer status,
and then click [Next >].
10. When the [<Auto-detect USB Port>] dialog box appears, connect this printer to the computer
using a USB cable, and then turn the printer's main power switch on.
USB auto detection begins.
11. When the dialog box asking you to use this printer as the default printer appears, click either
key.
12. When a message appears informing you that the installation was successfully completed,
click [Finish].

Ricoh SP 311DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Printing colors	Black
Maximum duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6
Mobile printing technologies	Not supported
Total input capacity	300 sheets
Total output capacity	125 sheets
Maximum print size	210 x 297 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	890 W
Power consumption (printing)	- W
Power consumption (PowerSave)	50 W
Sustainability certificates	ENERGY STAR
Product color	Black, White
Supported network protocols	TCP/IP, IPP

Weight and Dimensions

Depth	382 mm
Width	370 mm
Height	262 mm
