3. After extension, check that the arrows on the extender and tray are aligned.
4. Follow Steps 2 to 6 in page 26 "Loading Paper into Tray1 and 2".
• To reinsert the extender, you might have to push it with moderate force.
Loading Paper into Bypass Tray
• Before printing on paper other than envelopes, make sure to pull up the levers on the machine rear,
inside the rear cover. Leaving the levers lowered can cause print quality problems when printing on
paper other than envelopes.
• Do not load paper while the machine is printing.
• Load paper with the print side up and in the short-edge feed direction.
• Curled paper may jam. Straighten curled paper before loading.
1. Open the bypass tray.
If you load A4 (297 mm) or larger size paper, pull out the bypass tray extension.
2. Paper Specifications and Adding Paper
30
