RIGOL Chapter 9 Histogram Analysis
9-4 MSO7000/DS7000 User Guide
 Sum: indicates the sum of all bins (buckets) in the histogram.
 Peaks: indicates the maximum number of hits in any single bin.
 Max: indicates the value that corresponds to the maximum bin that has any hits.
 Min: indicates the value that corresponds to the minimum bin that has any hits.
 Pk_Pk: indicates the Delta between the max. value and the min. value.
 Mean: indicates the average value of the histogram.
 Median: indicates the median value of the histogram.
 Mode: indicates the mode value of the histogram.
 Bin width: indicates the width of each bin (bucket) in the histogram.
 Sigma: indicates the standard deviation of the histogram.
To Reset
Press Reset to reset the statistical data and restart to make statistics.
