Chapter 1 Disassembly and Assembly RIGOL
DS8000-R Service Guide 3
Table 1-1 Replacement Parts List
No.
Part No.
Qty.
Name/Description
1
2010004774
1
Front Panel
2
1020004713
1
Rubber Keypad
3
2010004764
1
Probe Board
4
2010004767
2
Handle
5
1020004722
1
Metal Front Panel
6
1020004724
2
Hanging Ear
7
1020003428
1
M4x8 Torx Pan Head Screw
8
1020004764
4
Pad
9
2010004757
1
Main Board
10
1010002308
8
BeCu Fingerstock (Slot Mount-4)
11
1020004721
1
Fan Bracket
12
1020000573
3
M3x20 Torx Pan Head Combination Screw
13
1020004765
1
Fan Components
14
1020004720
1
Metal Chassis
15
1010005871
1
Power Cord Connector
16
1020004762
1
Mylar Film
17
1010005841
2
BeCu Fingerstock (Slot Mount-2)
18
1020004774
23
M3x6 Torx Flat Head Countersunk Screw
19
2010004759
1
Interface Board
20
1020000619
2
BNC Nut
21
1010006726
3
SMA Cable
22
—
3
SMA Nut
23
2010003934
1
Power Supply Board
24
1020004763
4
Multiple-station Screw
25
1010006704
1
Isolation Board
26
1020000571
24
M3x6 Torx Pan Head Combination Screw
27
1020004723
1
Metal Cover
The recommended disassembly procedures are as follows:
Disassemble the Metal Cover → Disassemble the Hanging Ear → Disassemble the Front Panel
Assembly → Disassemble the Metal Front Panel → Disassemble the Probe Board → Disassemble the
Fan Components → Disassemble the Main Board → Disassemble the Power Supply Board →
Disassemble the SMA Cable → Disassemble the Interface Board
