Chapter 1 Disassembly and Assembly RIGOL
MSO8000 Service Guide 1-13
Disassemble the Knob
Figure 1-10 Disassemble the Knob
Part Description:
① 6 large knobs
② 8 small knobs
Disassembly Step:
Pull out the large and small knobs from the front panel.
Panel
①
①
①
①
①
①
②
②
②
②
②
②
②
②
