Chapter 3 Functions of the Front Panel of RTSA RIGOL
RSA5000 User Guide 3-25
Meas Setup
Open the parameter setting menu of the function selected in the Meas menu. In the
Meas Setup menu, only the menu items related to the current measurement
function are displayed. Please view the relevant menus according to the current
measurement function.
Avg Number
Specifies the number of times for averaging the measurement results. The average
value is displayed in a real-time manner after each measurement is completed.
Table 3-10 Average Count
Parameter
Remarks
Default
10
Range
1 to 1,000
Unit
None
Knob Step
1
Left/Right Arrow Key Step
Up/Down Arrow Key Step
1
Limit
Sets the parameters of limit lines. For details, refer to "Limit" in Chapter 2. Only
when you select "Normal" view, can the limit line operation be available.
Meas Preset
Restores all parameters of the current measurement mode to their preset values,
without clearing the limit line.
