Rigol RSA5000 Series User Manual

RIGOL Chapter 2 Functions of the Front Panel of GPSA
2-2 RSA5000 User Guide
Basic Settings
FREQ
Sets the frequency parameters of the analyzer. The analyzer sweeps within a
specified frequency range and restarts sweeping every time the frequency
parameters are modified.
The frequency range of a channel can be expressed by either of two groups of
parameters: Start Frequency/Stop Frequency (
start
f
/
st op
f
); or Center
Frequency/Span (
center
f
/
span
f
). If any of the four parameters is changed, the other
three parameters will make adjustment automatically to ensure the coupling
relationship among them:
2)(
startstopcenter
fff +=
(2-1)
startstopspan
fff −=
(2-2)

Rigol RSA5000 Series Specifications

General

Resolution Bandwidth (RBW)	1 Hz to 10 MHz
VBW Range	1 Hz to 10 MHz
Maximum Input Power	+30 dBm
Bandwidth	40 MHz
Display	10.1 inch LCD Touch Screen
Input Impedance	50 Ω
Power Supply	100 V - 240 V AC, 50 Hz - 60 Hz
Real-Time Bandwidth (RTBW)	40 MHz
Sweep Time	1 ms to 1000 s
Display Resolution	1280 x 800
Interface	LAN, USB, HDMI
