12 Value Series Manual
Mount to Wall
wall installaon
brackets
Checklist to Determine Installaon
Locaon
□ The water heater is not exposed to corrosive
compounds in the air.
□ The water heater locaon complies with the
clearances.
□ For indoor models, the planned venng will not
exceed the maximum length for the number of
elbows used.
□ The planned venng terminaon/air intake
locaon meets the clearances.
□ The water supply does not contain chemicals or
exceed total hardness that will damage the heat
exchanger.
□ A standard 3 prong 120 VAC, 60 Hz properly
grounded wall outlet (for indoor models) or other
120 VAC, 60 Hz source is available.
□ The installaon must conform with local codes or,
in the absence of local codes, with the Naonal
Fuel Gas Code, ANSI Z223.1/NFPA 54, or the
Natural Gas and Propane Installaon Code, CSA
B149.1. If installed in a manufactured home, the
installaon must conform with the Manufactured
Home Construcon and Safety Standard, Title 24
CFR, Part 3280 and/or CAN/SCA Z240 MH Series,
Mobile Homes.
□ Leave the enre manual taped to the water
heater (indoor models), temperature controller
(outdoor models), or give the enre manual
directly to the consumer.
1. Idenfy the installaon locaon and conrm that
the installaon will meet all required clearances.
2. Securely aach the water heater to the wall
using any of the holes in the wall installaon
brackets which are at the top and boom of the
water heater. Ensure that the aachment
strength is sucient to support the weight.
Refer to the weight of the water heater in the
Specicaons secon.
Use a leveling tool to ensure that the water
heater is level. Proper operaon requires that
the water heater be level.
NOTE: The water heater should be installed in an
upright posion. Do not install upside down or on its
side.
Remove the Front Panel
Slide the plasc trim pieces on each side of the water
heater to expose the screws.
Remove the 4 screws and pull o the front panel.
To Next Page
