i-COMM™ CONTROLLER
Pub. No. RHSPI388 JANUARY 2006 7
i-COMM DIGITAL CONTROLLER INSTRUCTIONS
Valid Values for Output Settings
Value Function
0 On when door closed (Interlock Out)
1 On when door Not Closed
2 On during preannounce to close
3 On when door full open
4 On when door not full open
5 On when door faulted
6 On when door not faulted
7 On when activation command
8 On during run Open
9 On during run Close
10 On during run (Open or Close)
11 On when door on limit (open or close)
12 On when I-Zone alarm
13 On when door open for 30 seconds
14 On when door open for 60 seconds
15 On when door open for 120 seconds
16 On during sequential activation
17 On when not running open
18 On when not running close
19 On when not running (open or close)
20 Output Disabled
Default Value for Output (Factory Configuration)
Model: YK2 YK3 YDC0 YDC1 YDC2 YDC3
Protecdor/CL n/a 0 2 20 20 20
Protecdor/CL PRO n/a 0 2 20 20 n/a
Protecdor XL n/a 0 2 20 20 20
Protecdor XL PRO n/a 0 2 20 20 20
Trakline 20 0 2 20 20 20
Iso-Tek n/a 0 2 20 20 20
Barrier Glider n/a 0 2 20 20 n/a
Barrier Fold n/a 0 2 20 20 20
n/a = Not available for change
DETAILED MENU LISTING:
"Output Definition" Read-Write Use to change functions of outputs where allowed. YK2, YK3, YDC0,
(see chart) (Note: Outputs which are not changeable will display "Not Adjustable")
YDC1, YDC2, YDC3
