Rittal CMC III User Manual

Rittal CMC III online comfort handle VX 15
8 Technical specifications
EN
8 Technical specifications
Technical specifications CMC III online comfort handle VX
Model no. DK7030.610/DK7030.611
W x H x D (mm) 41 x 386 x 42, door-mounted
Rated voltage 24 V DC
Rated current max. 100 mA
Operating temperature range +5°C…+55°C
Operating humidity range 5%…70% relative humidity, non-condensing
Protection category IP30 to IEC 60 529
Connection cable 2.9m with RJ12 connector
Operation/signals 1 x Multi-LED
Tab. 2: Technical specifications
