Rockwell Automation 440R-S12R2 User Manual

78 Rockwell Automation Publication 440R-UM013F-EN-P - July 2021
Appendix A Specifications
Reset Input Specifications
B1 Input Specifications
Test Out
Pulse
Duration [ms] 2.5 1.5, 3 — — 1.5, 3
Period [ms] 14 13.6 — — 13.6
Off Pulse Accepted for OSSD
Setting Without Declaring the
Input as OFF, Max [ms]
3.1 2.2 — — 2.2
Recovery Time, Min [ms] 30 — — 30
Reverse Voltage Protection Yes — — Yes
Input Capacitance [nF] 10 — — 10
Input Simultaneity Infinite — — Infinite
Allowable Input Resistance,
Max (Ω)
900 ——900
Allowable
Cable
Capacitance,
Max [nF]
S11 to S21 350 160 — — 160
S11 to Ground350320 ——320
S21 to Ground350320 ——320
Safety Mat, Max Size [m
²
]
2335 ——35
Attribute 440R-S13R2 (CI) 440R-D22R2 (DI) 440R-D22S2 (DIS) 440R-EM4R2 (EM) 440R-EM4R2D (EMD) 440R-S12R2 (SI)
Attribute 440R-S13R2 (CI) 440R-D22R2 (DI) 440R-D22S2 (DIS) 440R-EM4R2 (EM) 440R-EM4R2D (EMD) 440R-S12R2 (SI)
Wiring Terminal S34 — — S34
ON Voltage
Max [V] 26.4 — — 26.4
Min [V] 11 — — 11
OFF Voltage, Max [V] 5 — — 5
OFF Current, Max [mA] 2 — — 2
ON Current,
Max
At 24V DC [mA]11.0 ——11.0
At 26.4VDC [mA] 11.1 — — 11.1
Galvanic Isolation:
I/O from Logic
No ——No
Overvoltage Protection Yes — — Yes
Input Capacitance [nF] 10 — — 10
Duration [s]0.5…3.0 ——0.5…3.0
Attribute 440R-S13R2 (CI) 440R-D22R2 (DI) 440R-D22S2 (DIS) 440R-EM4R2 (EM) 440R-EM4R2D (EMD) 440R-S12R2 (SI)
Wiring Terminal — — — — B1 —
ON Voltage
Max [V] — — — — 26.4 —
Min [V] — — — — 11 —
OFF Voltage, Max [V]————5 —
OFF Current, Max [mA] — — — — 2 —
ON Current,
Max
At 24V DC [mA] — — — — 11.0 —
At 26.4VDC [mA] — — — — 11.1 —
Galvanic Isolation: I/O from
Logic
————No—
Overvoltage Protection — — — — Yes —
Input Capacitance [nF] — — — — 10 —
