29Publication 1769-UM020A-EN-P - December 2009 29
Chapter
3
Module Data, Status, and Channel
Configuration
Introduction
Module Addressing
This memory map shows the output, input, and configuration tables
for the module.
Memory Map
Topic Page
Module Addressing 29
Input Data File 31
Output Data File 32
Configuration Data File 33
Channel Configuration 34
Slot e
Input Image
File
Output Image
File
Configuration
File
Slot e
Slot e
Input
5 Words
Output
5 Words
Configuration
File
32 Words
Channel 3 Configuration Words
Words 24…31
Channel 1 Data Word Word 1
Output Clamp Status Bits
Word 0
Channel 2 Configuration Words
Words 16…23
Channel 1 Configuration Words
Words 8…15
Word 2
Data Echo Channel 3
Word 4
Data Echo Channel 1
Word 2
Bit 0
Channel 2 Data Word
Bit 15
Data Echo Channel 0
Word 1
Data Echo Channel 2
Word 3
Channel 0 Data Word Word 0
Word 3
Channel 3 Data Word
Word 4
Cancel Output Clamp Latch Bits
Channel 0 Configuration Words
Words 0…7
