Module Data, Status, and Channel Configuration Chapter 3
Configuration Data File
The configuration file lets you determine how each individual output
channel will operate. Parameters such as the output type and data
format are set up by using this file. This data file is writable and
readable. The default value of the configuration data table is all zeros.
For information on configuring the module by using MicroLogix 1500
and RSLogix 500 software, see Appendix
B; for CompactLogix and
RSLogix 5000 software, see Appendix C
.
The configuration file can also be modified through the control
program, if supported by the controller. The structure and bit settings
are shown in Channel Configuration
on the following page.
Configuration Data File
Word/Bit 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Word 0 EC NU EHI ELI LC ER FM PM NU PFE
Word 1 NU Format Ch0 NU Type/Range Sel Ch0
Word 2 SGN Fault Value Channel 0
Word 3 SGN Program (Idle) Value Channel 0
Word 4 SGN Clamp High Data Value Channel 0
Word 5 SGN Clamp Low Data Value Channel 0
Word 6 SGN Ramp Rate Channel 0
Word 7 NU
Word 8 EC NU EHI ELI LC ER FM PM NU PFE
Word 9 NU Format Ch1 NU Type/Range Sel Ch1
Word 10 SGN Fault Value Channel 1
Word 11 SGN Program (Idle) Value Channel 1
Word 12 SGN Clamp High Data Value Channel 1
Word 13 SGN Clamp Low Data Value Channel 1
Word 14 SGN Ramp Rate Channel 1
Word 15 NU
Word 16 EC NU EHI ELI LC ER FM PM NU PFE
Word 17 NU Format Ch2 NU Type/Range Sel Ch2
Word 18 SGN Fault Value Channel 2
Word 19 SGN Program (Idle) Value Channel 2
Word 20 SGN Clamp High Data Value Channel 2
Word 21 SGN Clamp Low Data Value Channel 2
Word 22 SGN Ramp Rate Channel 2
Word 23 NU
Word 24 EC NU EHI ELI LC ER FM PM NU PFE
Word 25 NU Format Ch3 NU Type/Range Sel Ch3
Word 26 SGN Fault Value Channel 3
Word 27 SGN Program (Idle) Value Channel 3
Word 28 SGN Clamp High Data Value Channel 3
Word 29 SGN Clamp Low Data Value Channel 3
Word 30 SGN Ramp Rate Channel 3
Word 31 NU
