Publication 1769-UM020A-EN-P - December 2009 47
Module Diagnostics and Troubleshooting Chapter 4
Error Codes
Error codes can help troubleshoot your module.
During system configuration, if you set the fields in the configuration
file to invalid or unsupported values, the module generates a
configuration error and the system controller enters a Fault condition.
The invalid configuration data must be corrected and the program
downloaded again for the system to enter Run mode. You cannot
change module configuration data while the system is in Run mode.
Any changes are ignored by the module, which continues to operate
with its previous configuration.
Extended Error Codes for Hardware Errors
Error Type Hex
Equivalent
(1)
Module
Error
Code
Extended Error
Information
Code
Error Description
Binary Binary
No Error X000 000 0 0000 0000 No error
General Common
Hardware Error
X200 001 0 0000 0000 General hardware error; no additional information
X201 001 0 0000 0001 Power-up reset state
Hardware-
specific Error
X300 001 1 0000 0000 General hardware error
X301 001 1 0000 0001 Microprocessor hardware error
X302 001 1 0000 0010 D/A converter communication error
(1) X represents the Don’t Care digit. Module hardware error codes are typically presented in their Hex Equivalent by the programming software.
Extended Error Codes for Configuration Errors
Hex Equivalent
(1)
Module
Error Code
Extended Error
Information Code
Error Description
Binary Binary
X400 010 0 0000 0000 General configuration error; reserve bits set to 1
X401 010 0 0000 0001 Invalid output range selected (channel 0)
X402 010 0 0000 0010 Invalid output range selected (channel 1)
X403 010 0 0000 0011 Invalid output range selected (channel 2)
X404 010 0 0000 0100 Invalid output range selected (channel 3)
X405 010 0 0000 0101 Invalid output format selected (channel 0)
X406 010 0 0000 0110 Invalid output format selected (channel 1)
X407 010 0 0000 0111 Invalid output format selected (channel 2)
X408 010 0 0000 1000 Invalid output format selected (channel 3)
X409 010 0 0000 1001 Invalid fault value (channel 0)
X40A 010 0 0000 1010 Invalid fault value (channel 1)
X40B 010 0 0000 1011 Invalid fault value (channel 2)
X40C 010 0 0000 1100 Invalid fault value (channel 3)
