48 Publication 1769-UM020A-EN-P - December 2009
Chapter 4 Module Diagnostics and Troubleshooting
Invalid Output Range Selected
These error codes occur when the 4-bit output range code for the
indicated channel is not one of the assigned output range codes for
the module.
See Bit Definitions for Type/Range and Data Format Configuration
Words on page 34 for details on the assigned output range codes for
the module.
Invalid Output Format Selected
These error codes occur when the 3-bit output format code for the
indicated channel is not one of the assigned output format codes for
the module.
See Bit Definitions for Type/Range and Data Format Configuration
Words on page 34 for details on the assigned output range codes for
the module.
X40D 010 0 0000 1101 Invalid program/idle value (channel 0)
X40E 010 0 0000 1110 Invalid program/idle value (channel 1)
X40F 010 0 0000 1111 Invalid program/idle value (channel 2)
X410 010 0 0001 0000 Invalid program/idle value (channel 3)
X411 010 0 0001 0001 Invalid clamp value (channel 0)
X412 010 0 0001 0010 Invalid clamp value (channel 1)
X413 010 0 0001 0011 Invalid clamp value (channel 2)
X414 010 0 0001 0100 Invalid clamp value (channel 3)
X415 010 0 0001 0101 Invalid ramp rate (channel 0)
X416 010 0 0001 0110 Invalid ramp rate (channel 1)
X417 010 0 0001 0111 Invalid ramp rate (channel 2)
X418 010 0 0001 1000 Invalid ramp rate (channel 3)
(1) X represents the Don’t Care digit. Module configuration error codes are typically presented in their Hex Equivalent by the programming software.
Extended Error Codes for Configuration Errors
Hex Equivalent
(1)
Module
Error Code
Extended Error
Information Code
Error Description
Binary Binary
