P-4
Overview
Catalog Number Explanation
Code Voltage Ph.
V 120V AC 1
A 240V AC 1
B 240V AC 3
D 480V AC 3
Code
Version
4 RS485
Code
Interface Module
1 Fixed Keypad
Code
Enclosure
N Panel Mount - IP 20 (NEMA Type Open)
22A - A 1P5 N 1 1 4
Drive Dash Voltage Rating Rating Enclosure HIM Emission Class Comm Slot
Output Current @ 100-120 Input or 200-240V Input
Code Amps kW (HP)
1P5 1.5 0.2 (0.25)
2P3 2.3 0.37 (0.5)
4P5 4.5 0.75 (1.0)
8P0 8.0 1.5 (2.0)
012 12 2.2 (3.0)
017 17.5 3.7 (5.0)
Code Rating
0 No Filter
1 Integral EMI Filter
Output Current @ 380-480V Input
Code Amps kW (HP)
1P4 1.4 0.37 (0.5)
2P3 2.3 0.75 (1.0)
4P0 4.0 1.5 (2.0)
6P0 6.0 2.2 (3.0)
8P7 8.7 3.7 (5.0)
Code
22A PowerFlex 4
