Appendix B
Accessories and Dimensions
Table B.A Catalog Number Description
Table B.B PowerFlex 4 Drives
For information on… See page
Product Selection B-1
Product Dimensions B-5
Product Selection
22A - A 1P5 N 1 1 4
Drive Voltage Rating Rating Enclosure HIM Emission Class Comm Slot
Drive Ratings
Catalog Number
Frame
SizeInput Voltage kW HP Output Current
120V 50/60 Hz
1-Phase
No Filter
0.2 0.25 1.5A 22A-V1P5N104 A
0.37 0.5 2.3A 22A-V2P3N104 A
0.75 1.0 4.5A 22A-V4P5N104 B
240V 50/60 Hz
1-Phase
With Integral “S Type”
EMC Filter
0.2 0.25 1.5A 22A-A1P5N114 A
0.37 0.5 2.3A 22A-A2P3N114 A
0.75 1.0 4.5A 22A-A4P5N114 A
1.5 2.0 8.0A 22A-A8P0N114 B
240V 50/60 Hz
1-Phase
No Filter
0.2 0.25 1.5A 22A-A1P5N104 A
0.37 0.5 2.3A 22A-A2P3N104 A
0.75 1.0 4.5A 22A-A4P5N104 A
1.5 2.0 8.0A 22A-A8P0N104 B
240V 50/60 Hz
3-Phase
No Filter
0.2 0.25 1.5A 22A-B1P5N104 A
0.37 0.5 2.3A 22A-B2P3N104 A
0.75 1.0 4.5A 22A-B4P5N104 A
1.5 2.0 8.0A 22A-B8P0N104 A
2.2 3.0 12.0A 22A-B012N104 B
3.7 5.0 17.5 22A-B017N104 B
480V 50/60 Hz
3-Phase
No Filter
0.37 0.5 1.4A 22A-D1P4N104 A
0.75 1.0 2.3A 22A-D2P3N104 A
1.5 2.0 4.0A 22A-D4P0N104 A
2.2 3.0 6.0A 22A-D6P0N104 B
3.7 5.0 8.7A 22A-D8P7N104 B
