Programming and Parameters 3-3
Display Group
d001 [Output Freq]
Related Parameter(s): d002, d010, P034, P035
Output frequency present at T1, T2 & T3 (U, V & W).
Values Default Read Only
Min/Max: 0.0/P035 [Maxim
um Freq]
Display: 0.1 Hz
d002 [Commanded Freq]
Related Parameter(s): d001, P034, P035, P038
Value of the active frequency command. Displays the commanded frequency even if the drive is not
running.
Important: The frequency command can come from a number of sources. Refer to Star
t and Speed
Reference Control on page 1-17 for details.
Values Default Read Only
Min/Max: 0.0/P035 [Maximum Freq]
Display: 0.1 Hz
d003 [Output Current]
The output current present at T1, T2 & T3 (U, V & W).
Values Default Read Only
Min/Max: 0.00/Drive Rated Amps × 2
Display: 0.01 Amps
d004 [Output Voltage]
Related Parameter(s): P031, A084, A088
Output voltage present at terminals T1, T2 & T3 (U, V & W).
Values Default Read Only
Min/Max: 0/Drive Rated Volts
Display: 1 VAC
d005 [DC Bus Voltage]
Present DC bus voltage level.
Values Default Read Only
Min/Max: Based on Drive Rating
Display: 1 VDC
