10
MAY.2002
PARTS LIST
fig.part1e
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
CONSIDERATION ON PARTS ORDRING
When ordering any parts listed in the parts list, please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or even
undelivered replacement.
NOTE: The parts marked # are new. (initial parts)
CASING Q'ty
# 02896756 TOP CASE 1
# 02896801 CDRW COVER 1
# 02896767 BOTTOM COVER 1
# 02896789 DISPLAY COVER 1
CHASSIS
# 02896778 CHASSIS 1
# 02896812 HDD HOLDER L 1
# 02896823 HDD HOLDER R 1
# 02899401 DD HOLDER CDRW L BR-1180CD ONLY 1
# 02899412 DD HOLDER CDRW R BR-1180CD ONLY 1
# 02899434 DD HOLDER CDRW STOP BR-1180CD ONLY 1
KNOB, BUTTON
02013090 F C-KEYTOP MX1H CLR 12
00900145 D S-KEYTOP SD1H BLK 6
00900156 D S-KEYTOP SD2H BLK 2
00900167 D S-KEYTOP SD3H BLK 1
00900189 D S-KEYTOP SX1H BLK 2
00900190 D S-KEYTOP SX2H BLK 2
00904245 D S-KEYTOP SX3H BLK 1
00904256 D S-KEYTOP SX4H BLK 1
01234090 D T-KEYTOP MX4B BLK 1
01670512 F C-KEYTOP SX1H BLK 2
01783945 N S-KEYTOP MD3H 1
02011456 Y S-KEYTOP SX1H BLK 1
02123467 F C-KEYTOP MX1H BLK 1
22495271 DS-KEYTOP MX4H BLK 249-271 1
22495277 D S-KEYTOP MD1H BLK 249-277(W/WINDOW) 1
02457512 J R-KNOB SFA BLK/LCG 3
01340412 P R-KNOB SF-A BLK/LCG 1
22485303 D R-KNOB(ALPHA-DIAL) L BLK 248-303 1
01902289 U S-KNOB M BLK LCG 11
SWITCH
01340290 EVQ11A H=5.0 TACT SWITCH SW1,SW2,SW3,SW4,SW5,SW6,SW7,SW8,SW9,S
W10,SW11,SW12,SW13,SW14,SW15,SW16,SW17,
SW18,SW19,SW20,SW21,SW22,SW23,SW24,SW2
5,SW26,SW27,SW28,SW29,SW30,SW31,SW32,SW
33,SW34,SW35,SW36,SW37,SW38,SW39,SW40,S
W41,SW42,SW43,SW44,SW45,SW46,SW47,SW48,
SW49,SW50,SW51,SW52,SW53,SW54 on SWB
54
JACK, EXT TERMINAL
13429825 YKF51-5054 2PZ MIDI CONNECTOR JK9 on MB 1
00569278 LGR4609-7100 6.5MM JACK JK1 on ANB. JK7,10,11 on MB 4
# 02900312 HEC0470-01-640 DC JACK JK8 on MB 1
01239890 NC3FAH2-0 XLR JACK JK2,JK4 on ANB 2
# 02900478 YKC21-3282 RCA(PIN JACK) JK5 on ANB 1
13449258 HLJ4306-01-3080 6.5MM JACK JK3,JK6 on ANB. 2
DISPLAY UNIT
17041159 F-51320GNY-LY-AA W/TAPE LCD 1
NOTE: Replacement F-51320GNY-LY-AA should be made on a unit base.
To Next Page
