BR-1180
LOCATION OF CONTROLS PARTS LIST
No. PART CODE PART NAME DESCRIPTION Q’TY
1 00569278 6.5MM JACK LGR4609-7100 4
2 01239890 XLR JACK NC3FAH2-0 2
3 13449258 6.5MM JACK HLJ4306-01-3080 2
4 02900478 RCA(PIN JACK) YKC21-3282 1
5 01340412 P R-KNOB SF-A BLK/LCG 1
02900467 9M/M ROTARY POTENTIOMETER EVJC25FB6A54 50KAX2 1
6 02568778 IC (OPTICAL CONNECTOR) GP1FA350TZ 1
7 13429825 MIDI CONNECTOR YKF51-5054 2PZ 1
8 02900312 DC JACK HEC0470-01-640 1
9 22365714 CORD HOOK 236-714 1
10 02896767 BOTTOM COVER 1
11 02896756 TOP CASE 1
12 02011456 Y S-KEYTOP SX1H BLK 1
01340290 TACT SWITCH EVQ11A H=5.0 1
13 22485303 D R-KNOB(ALPHA-DIAL) L BLK 248-303 1
01905467 ROTARY ENCODER EVE GC1 F20 24B 1
14 00900190 D S-KEYTOP SX2H BLK 2
01340290 TACT SWITCH EVQ11A H=5.0 2
15 01234090 D T-KEYTOP MX4B BLK 1
01340290 TACT SWITCH EVQ11A H=5.0 4
16 02013090 F C-KEYTOP MX1H CLR 12
01340290 TACT SWITCH EVQ11A H=5.0 12
01904178 LED (CLR) SPR-505MVWT31 12
17 01670512 F C-KEYTOP SX1H BLK 2
01340290 TACT SWITCH EVQ11A H=5.0 2
18 02123467 F C-KEYTOP MX1H BLK 1
01340290 TACT SWITCH EVQ11A H=5.0 1
19 01783945 N S-KEYTOP MD3H 1
01340290 TACT SWITCH EVQ11A H=5.0 3
15029348 LED (GREEN) SLR-342MCT32 (PLAY) 1
01904112 LED SLR-342VCT32 .NP.Q RANK (REC)
20 00900145 D S-KEYTOP SD1H BLK 6
01340290 TACT SWITCH EVQ11A H=5.0 6
01904112 LED SLR-342VCT32 N.P.Q RANK 6
21 00900156 D S-KEYTOP SD2H BLK 2
01340290 TACT SWITCH EVQ11A H=5.0 4
01904112 LED SLR-342VCT32 N.P.Q RANK 4
22 00900189 D S-KEYTOP SX1H BLK 1
01340290 TACT SWITCH EVQ11A H=5.0 1
23 00904245 D S-KEYTOP SX3H BLK 1
01340290 TACT SWITCH EVQ11A H=5.0 3
24 00904256 D S-KEYTOP SX4H BLK 1
01340290 TACT SWITCH EVQ11A H=5.0 4
25 02457512 J R-KNOB SFA BLK/LCG 2
02896701 9M/M ROTARY POTENTIOMETER EVUF2K4A15 100KA 2
26 22495277 D S-KEYTOP MD1H BLK 249-277(W/WINDOW) 1
01340290 TACT SWITCH EVQ11A H=5.0 1
01904112 LED SLR-342VCT32 N.P.Q RANK 1
27 01902289 U S-KNOB M BLK LCG 11
01677312 POTENTIOMERTER (SLIDE) EWAP1AC10 B54 50KB 11
28 00900167 D S-KEYTOP SD3H BLK 1
01340290 TACT SWITCH EVQ11A H=5.0 3
01904112 LED SLR-342VCT32 N.P.Q RANK 3
29 22495271 DS-KEYTOP MX4H BLK 249-271 1
01340290 TACT SWITCH EVQ11A H=5.0 4
30 22355334 FOOT MKS 235-334 4
31 02896789 DISPLAY COVER 1
17041159 LCD F-51320GNY-LY-AA W/TAPE 1
32 02896790 PANEL SHEET 1
33 02457512 J R-KNOB SFA BLK/LCG 1
02896712 9M/M ROTARY POTENTIOMETER EVUF2KFK4B54 50KB 1
34 01904189 LED SEL2210R D RANK 3
35 15039237 LED SLR-342MC3F (GREEN) 1
36 15029347 LED (RED) SLR-342VC3F 1
