16
MAY.2002
5. Press [YES].
* If you are in the process of recording a song at this point, the message “Save
Current?” may appear. If you want to save the current song to the hard disk,
press [YES]; press [NO] if you do not need to save the song. Note, though, that if
you do press [NO], the data currently being recorded will be lost.
The message “Write Speed?” appears.
fig.R16-92
6. Set the write speed.
If the write speed indicated is acceptable, go on to Step 8.
If you want to change the write speed, rotate the TIME/VALUE dial to
change the value, then proceed to Step 7.
Write Speed:
x2 (352 kbps) Writes twice as fast.
x4 (704 kbps) Writes four times as fast.
x8 (1408 kbps) Writes eight times as fast.
* With some media, the range of write speeds may be limited. In such cases, the
values that can be set with the TIME/VALUE dial may also be limited.
7. Press [ENTER].
The message “Write Sure?” appears.
* To cancel, press [NO].
8. Press [ENTER].
Writing to the CD-R/RW disc begins.
The backup begins.
When “Complete!” appears, the backup is finished.
* If the content of the hard disk does not fit on one CD-R/RW disc, the backup is
then made to multiple discs. In this case, have a number of blank discs on hand,
and replace the discs according to the instructions as they appear on the screen.
Loading the saved content of the
hard disk to the BR-1180CD
(HDD Recover)
1. Place the CD-R/RW disc containing the saved hard disk data in the CD-
R/RW drive.
2. After the CD-R/RW drive’s indicator has stopped flashing, press [DATA
SAVE/LOAD].
3. Use [CURSOR] to select the “RECOVER” icon then press [ENTER].
fig.R16-06
4. Using [CURSOR] again to move the cursor to “HDD,” then press
[ENTER].
The message “HDD Recover Ok?” appears.
fig.R16-55
5. Press [YES], and when the message “Initialize HDD?” appears, press
[YES] again.
The hard disk is initialized, then the recovery begins.
When “Complete!” appears, the loading is finished.
* When you execute HDD Recover, all data stored on the hard disk up to that
point is erased and overwritten by the data on the CD-R/RW disc. Note that this
data cannot be recovered once it has been erased.
RESTORING THE FACTORY
SETTINGS
Initializing hard disk
* Note that all user and demo song data are lost when this operation is performed.
1. Press the [POWER] button while pressing the [REC TRACK5] and
[UNDO/REDO] buttons.
Continue pressing the switch until 1 TEST MENU is displayed.
2. Select “23 INITIALIZE HDD” by turning the [TIME/VALUE] knob.
3. Press the [ENTER] button.
4. “Initialize OK?” is displayed.
5. Press the [ENTER] button again.
The initializing begins .
6. “24 POWER OFF” is displayed.
7. The unit’s power is turned off when the [POWER] button is pressed for at
least 2 seconds.
Loading the demo song
* Note that all user data are lost when this operation is performed.
* There is data which is not initialized only by load operation of a Demo song.
Please operate the above “Initializing hard disk” when you exchange the hard
disk.
1. Press the [POWER] button while pressing the [REC TRACK7] and
[UNDO/REDO] buttons.
Continue pressing the button until “Insert Disc” is displayed.
2. Place the CD-R (#17041161) for loading the demo song on the tray.
3. “Initialize HDD?” is displayed.
4. Press [ENTER]
The hard disk is initialized, then the loading demo song begins.
5. The unit’s power will be turned off automatically.
