32
5-6 Front Loading
You can use the front-loading feature of the CX-500/400/300, which lets you load roll material at the front of the machine, by
installing the sheet hanger on the front.
Installing the Sheet Hanger
Install the sheet hanger on the front of the machine.
For an explanation of how assemble the unit and the stand
(PNS-502/402/302), refer to the “ASSEMBLY INSTRUC-
TIONS” included with the stand.
Loading Material
1
Refer to “4-1 Loading the Material (Roll Material)”
and load the material.
2
At [SELECT SHEET], select either [ROLL] or [R-
EDGE]. Do not select [F-EDGE].
3
Follow the steps in “Setting the Origin Point” in the
next section to set a new origin point. In particular, not
that if you have selected [R-EDGE], cutting cannot be
performed unless you set a new origin point.
You cannot perform a cutting test immediately after you have selected [R-EDGE]. Use the [ ] key to feed the material
several centimeters (1 or 2 inches) toward the rear, then execute the cutting test. There is no particular need to set the
origin point.
To Next Page
