MIDI Implementation

●Part Parameters

This instrument has 16 parts. Parameters that can be set individually for each Part are called Part parameters.

If you use exclusive messages to set Part parameters, specify the address by Block number rather than Part Number (normally the same number as the MIDI channel). The Block number can be

specified as one of 16 blocks, from 0 (H) to F (H).

The relation between Part number and Block number is as follows.

x...BLOCK NUMBER (0-F),Part 1 (MIDI ch = 1) x = 1

Part 2 (MIDI ch = 2) x = 2

: : :

Part 9 (MIDI ch = 9) x = 9

Part10 (MIDI ch = 10) x = 0

Part11 (MIDI ch = 11) x = A

Part12 (MIDI ch = 12) x = B

: : :

Part16 (MIDI ch = 16) x = F

Address (H) Size (H) Data (H) Parameter Description Default Value (H) Description

40 1x 00 00 00 02 00-7F TONE NUMBER CC#00 VALUE 0-127 00 0

40 1x 01# 00-7F P.C. VALUE 1-128 00 1

40 1x 02 00 00 01 00-10 Rx. CHANNEL 1-16, OFF Same as the Part Number

40 1x 03 00 00 01 00-01 Rx. PITCH BEND OFF/ON 01 ON

40 1x 04 00 00 01 00-01 Rx. CH PRESSURE (CAf) OFF/ON 01 ON

40 1x 05 00 00 01 00-01 Rx. PROGRAM CHANGE OFF/ON 01 ON

40 1x 06 00 00 01 00-01 Rx. CONTROL CHANGE OFF/ON 01 ON

40 1x 07 00 00 01 00-01 Rx. POLY PRESSURE (PAf) OFF/ON 01 ON

40 1x 08 00 00 01 00-01 Rx. NOTE MESSAGE OFF/ON 01 ON

40 1x 09 00 00 01 00-01 Rx. RPN OFF/ON 01 ON

40 1x 0A 00 00 01 00-01 Rx. NRPN OFF/ON 00 (01*) OFF (ON*)

* When “GM1 System On” and “GM2 System On” are received, Rx. NRPN will be set OFF. When “GS Reset” is received, it will be set ON.

40 1x 0B 00 00 01 00-01 Rx. MODULATION OFF/ON 01 ON

40 1x 0C 00 00 01 00-01 Rx. VOLUME OFF/ON 01 ON

40 1x 0D 00 00 01 00-01 Rx. PANPOT OFF/ON 01 ON

40 1x 0E 00 00 01 00-01 Rx. EXPRESSION OFF/ON 01 ON

40 1x 0F 00 00 01 00-01 Rx. HOLD1 OFF/ON 01 ON

40 1x 10 00 00 01 00-01 Rx. PORTAMENTO OFF/ON 01 ON

40 1x 11 00 00 01 00-01 Rx. SOSTENUTO OFF/ON 01 ON

40 1x 12 00 00 01 00-01 Rx. SOFT OFF/ON 01 ON

40 1x 13 00 00 01 00-01 MONO/POLY MODE Mono/Poly 01 Poly

(= CC# 126 01 / CC# 127 00)

40 1x 15 00 00 01 00-02 USE FOR RHYTHM PART 0 = OFF 00 at x ≠0 OFF at x ≠0

1 = MAP1 01 at x = 0 MAP1 at x ≠0

2 = MAP2

* This parameter sets the Drum Map of the Part used as the Drum Part. This instrument can simultaneously (in different Parts) use up to two Drum Maps (MAP1, MAP2). With the initial

settings, Part10 (MIDI CH = 10, x = 0) is set to MAP1 (1), and other Parts are set to normal instrumental Parts (OFF (0)).

40 1x 16 00 00 01 28-58 PITCH KEY SHIFT -24 - +24 [semitones] 40 0 [semitones]

40 1x 17 00 00 02 08-F8 PITCH OFFSET FINE -12.0 - +12.0 [Hz] 08 00 0 [Hz]

40 1x 18# Use nibblized data.

* PITCH OFFSET FINE allows you to alter, by a specified frequency amount, the pitch at which notes will sound. This parameter differs from the conventional Fine Tuning (RPN #1) parameter

in that the amount of frequency alteration (in Hertz) will be identical no matter which note is played. When a multiple number of Parts, each of which has been given a different setting for

PITCH OFFSET FINE, are sounded by means of an identical note number, you can obtain a Celeste effect.

40 1x 19 00 00 01 00-7F PART LEVEL 0-127 64 100

(= CC# 7)

40 1x 1A 00 00 01 00-7F VELOCITY SENSE DEPTH 0-127 40 64

40 1x 1B 00 00 01 00-7F VELOCITY SENSE OFFSET 0-127 40 64

40 1x 1C 00 00 01 00-7F PART PANPOT -64 (RANDOM), 40 0 (CENTER)

-63 (LEFT) - +63 (RIGHT)

(= CC# 10, except RANDOM)

40 1x 1D 00 00 01 00-7F KEY RANGE LOW (C-1)-(G9) 00 C-1

40 1x 1E 00 00 01 00-7F KEY RANGE HIGH (C-1)-(G9) 7F G 9

40 1x 1F 00 00 01 00-5F CC1 CONTROLLER NUMBER 0-95 10 16

40 1x 20 00 00 01 00-5F CC2 CONTROLLER NUMBER 0-95 11 17
