MIDI Implementation

■Individual Parameters

Individual Parameter Transmission transmits data (or requests data) for one parameter as one exclusive message (one packet of “F0 ..... F7”).

In Individual Parameter Transmission, you must use the Address and Size listed in the following “Parameter Address Map.” Addresses marked at “#” cannot be used as starting addresses.

●System Parameters

Parameters related to the system of the device are called System Parameters.

Address (H) Size (H) Data (H) Parameter Description Default Value (H) Description

40 00 00 00 00 04 0018-07E8 MASTER TUNE -100.0 - +100.0 [cent] 00 04 00 00 0 [cent]

40 00 01# Use nibblized data.

40 00 02#

40 00 03#

* Refer to section 4. Supplementary material, “About tuning” (p. 15).

40 00 04 00 00 01 00-7F MASTER VOLUME 0-127 7F 127

(= F0 7F 7F 04 01 00 vv F7)

40 00 05 00 00 01 28-58 MASTER KEY-SHIFT -24 - +24 [semitones] 40 0 [semitones]

40 00 06 00 00 01 01-7F MASTER PAN -63 (LEFT) - +63 (RIGHT) 40 0 (CENTER)

40 00 7F 00 00 01 00 MODE SET 00 = GS Reset,

127 = Exit GS mode

(Rx. only)

* Refer to “System exclusive messages related to mode settings” (p. 4).

40 01 10 00 00 10 00-40 VOICE RESERVE Part 10 (Drum Part) 02 2

40 01 11# Part 1 06 6

40 01 12# Part 2 02 2

40 01 13# Part 3 02 2

40 01 14# Part 4 02 2

40 01 15# Part 5 02 2

40 01 16# Part 6 02 2

40 01 17# Part 7 02 2

40 01 18# Part 8 02 2

40 01 19# Part 9 02 2

40 01 1A# Part 11 00 0

40 01 :# :

40 01 1F# Part 16 00 0

* The sum total of voices in the voice reserve function must be equal to or less than the number of the maximum polyphony. The maximum polyphony of this instrument is 128. For

compatibility with other GS models, it is recommended that the maximum polyphony be equal or less than 24.

40 01 30 00 00 01 00-07 REVERB MACRO 00: Room 1 04 Hall 2

01: Room 2

02: Room 3

03: Hall 1

04: Hall 2

05: Plate

06: Delay

07: Panning Delay

40 01 31 00 00 01 00-07 REVERB CHARACTER 0-7 04 4

40 01 32 00 00 01 00-07 REVERB PRE-LPF 0-7 00 0

40 01 33 00 00 01 00-7F REVERB LEVEL 0-127 40 64

40 01 34 00 00 01 00-7F REVERB TIME 0-127 40 64

40 01 35 00 00 01 00-7F REVERB DELAY FEEDBACK 0-127 00 0

* REVERB MACRO is a macro parameter that allows global setting of reverb parameters. When you select the reverb type with REVERB MACRO, each reverb parameter will be set to the most

suitable value.

* REVERB CHARACTER is a parameter that changes the reverb algorithm. The value of REVERB CHARACTER corresponds to the REVERB MACRO of the same number.

40 01 38 00 00 01 00-07 CHORUS MACRO 00: Chorus 1 02 Chorus 3

01: Chorus 2

02: Chorus 3

03: Chorus 4

04: Feedback Chorus

05: Flanger

06: Short Delay

07: Short Delay (FB)

40 01 39 00 00 01 00-07 CHORUS PRE-LPF 0-7 00 0

40 01 3A 00 00 01 00-7F CHORUS LEVEL 0-12 40 64

40 01 3B 00 00 01 00-7F CHORUS FEEDBACK 0-127 08 8

40 01 3C 00 00 01 00-7F CHORUS DELAY 0-127 50 80

40 01 3D 00 00 01 00-7F CHORUS RATE 0-127 03 3

40 01 3E 00 00 01 00-7F CHORUS DEPTH 0-127 13 19

40 01 3F 00 00 01 00-7F CHORUS SEND LEVEL TO REVERB 0-127 00 0

* CHORUS MACRO is a macro parameter that allows global setting of chorus parameters. When you use CHORUS MACRO to select the chorus type, each chorus parameter will be set to the

most suitable value.
