MIDI Implementation
❍Effect 3 (Chorus Send Level) (Controller number 93)
Status 2nd bytes 3rd byte
BnH 5DH vvH
n = MIDI channel number: 0H-FH (ch.1-ch.16)
vv = Control value: 00H-7FH (0-127)
●Program Change
Status 2nd bytes
CnH ppH
n = MIDI channel number: 0H-FH (ch.1-ch.16)
pp = Program numbe: 00H-7FH (prog.1-prog.128)
●Pitch Bend Change
Status 2nd byte 3rd bytes
EnH llH mmH
n = MIDI channel number: 0H-FH (ch.1-ch.16)
mm, ll = Pitch Bend value: 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)
■System Realtime Message
●Realtime Clock
Status
F8H
●Active sensing
Status
FEH
* This will be transmitted constantly at intervals of approximately 250 ms.
■System exclusive messages
❍Identity Reply
Status Data byte Status
F0H 7EH, 10H, 06H, 02H, 41H, 42H, 00H, 00H, 16H, 04H, 01H, F7H [FP-7]
00H, 00H
F0H 7EH, 10H, 06H, 02H, 41H, 42H, 00H, 00H, 16H, 05H, F7H [FP-4]
01H, 00H, 00H
Byte Explanation
F0H Exclusive status
7EH ID number (universal non-realtime message)
10H Device ID (use the same as the device ID of Roland)
06H Sub ID#1 (General Information)
02H Sub ID#2 (Identity Reply)
41H ID number (Roland)
42H Device family code (LSB)
00H Device family code (MSB)
00H Device family number code (LSB)
16H Device family number code (MSB)
04H(05H) Software revision level
01H Software revision level
00H Software revision level
00H Software revision level
F7H EOX (End of Exclusive)
3. Parameter Address Map (Model ID =
42H)
This map indicates address, size, Data (range), Parameter, Description, and Default Value of
parameters which can be transferred using and “Data set 1 (DT1).”
All the numbers of address, size, Data, and Default Value are indicated in 7-bit
Hexadecimal-form.
■Address Block map
An outlined address map of the Exclusive Communication is as follows;
Address (H) Block
40 00 00 +------------------------------------+
| SYSTEM PARAMETERS |Individual
40 01 3F +------------------------------------+
40 1x 00 +------------------------------------+
| PART PARAMETERS |Individual
| (x = 0-F) |
40 2x 5A +------------------------------------+
41 m0 00 +------------------------------------+
| SRUM SETUP PARAMETERS |Individual
| (m = 0-1) |
41 m8 7F +------------------------------------+
48 00 00 +------------------------------------+
| SYSTEM PARAMETERS |Bulk
48 01 10 +------------------------------------+
| PART PARAMETERS |Bulk
48 1D 0F +------------------------------------+
49 m0 00 +------------------------------------+
| DRUM SETUP PARAMETER |Bulk
| (m = 0-1) |
49 mE 17 +------------------------------------+
There are two ways in which GS data is transmitted: Individual Parameter Transmission in
which individual parameters are transmitted one by one, and Bulk Dump Transmission in
which a large amount of data is transmitted at once.
