Roland FP-4 Midi Implementation

26
MIDI Implementation
●0150: Monaural Delay
A delay that provides a long delay time.
●0151: Modulation Delay
Adds modulation to the delayed sound.
●0152: Triple Tap Delay
Produces three delay sounds; center, left and right.
●0157: 3D Delay
This applies a 3D effect to the delay sound. The delay sound will be positioned 90 degrees
left and 90 degrees right.
No Parameter Value Description
1 Delay Mode 0 - 1 ms, note When this is set to “note,” the effect is
synchronized with the tempo.
2 Delay Time 0 - 127 1-2540 ms Delay time from when the original
sound is heard to when the delay
sound is heard (Hz)
3 Delay Time #1 0 - 21 note Delay time from when the original
sound is heard to when the delay
sound is heard (note)
4 Phase 0 - 1 NORMAL,
INVERSE
Phase of the delay (NORMAL: non-
inverted, INVERSE: inverted)
5 Feedback 49 - 89 0- +80 % Proportion of the delay sound that is
to be returned to the input
6 HF Damp 0 - 17 200-8000 Hz,
Bypass
Frequency at which the high-
frequency content of the delayed
sound will be cut (Bypass: no cut)
7 Pan 0 - 127 L64-63R Panning of the delay sound
8 Low Gain 0 - 30 -15- +15 dB Amount of boost/cut for the high-
frequency range
9 High Gain 0 - 30 -15- +15 dB Amount of boost/cut for the high-
frequency range
10 Balance #2 0 - 100 D100:0W-
D0:100W
Volume balance of the original sound
(D) and the delay sound (W)
11 Level 0 - 127 0-127 Output volume
No Parameter Value Description
1 Delay Left
Mode
0 - 1 ms, note When this is set to “note,” the effect is
synchronized with the tempo.
2 Delay Left 0 - 127 1-1270 ms Adjusts the time until the delay
sound is heard. (Hz)
3 Delay Left 0 - 21 note Adjusts the time until the delay
sound is heard. (note)
4 Delay Right
Mode
0 - 1 ms, note Settings of the Delay R
The parameters are the same as for
the Delay L.
5 Delay Right 0 - 127 1-1270 ms
6 Delay Right 0 - 21 note
7 Feedback Mode 0 - 1 Normal, Cross Selects the way in which delay sound
is fed back into the effect (See the
figures above.)
8 Feedback 49 - 89 0- +80 % Adjusts the amount of the delay
sound that’s fed back into the effect.
9 HF Damp 0 - 17 200-8000 Hz,
Bypass
Adjusts the frequency above which
sound fed back to the effect is filtered
out. If you don’t want to filter out any
high frequencies, set this parameter
to Bypass.
10 Rate Mode 0 - 1 Hz, note When this is set to “note,” the effect is
synchronized with the tempo.
11 Rate 1 - 127 0.05-10.00 Hz Frequency of modulation (Hz)
12 Rate 0 - 21 note Frequency of modulation (note)
13 Depth #1 0 - 127 0-127 Depth of modulation
14 Phase 0 - 90 0-180 deg Spatial spread of the sound
15 Low Gain 0 - 30 -15- +15 dB Gain of the low frequency range
16 High Gain 0 - 30 -15- +15 dB Gain of the high frequency range
17 Balance #2 0 - 100 D100:0W-
D0:100W
Volume balance between the direct
sound (D) and the delay sound (W)
18 Level 0 - 127 0-127 Output level
No Parameter Value Description
1 Delay Left
Mode
0 - 1 ms, note When this is set to “note,” the effect is
synchronized with the tempo.
2 Delay Left 0 - 127 1-2540 ms Adjusts the time until the delay
sound is heard. (Hz)
3 Delay Left 0 - 21 note Adjusts the time until the delay
sound is heard. (note)
4 Delay Right
Mode
0 - 1 ms, note Settings of the Delay R
The parameters are the same as for
the Delay L.
5 Delay Right 0 - 127 1-2540 ms
6 Delay Right 0 - 21 note
7 Delay Center
Mode
0 - 1 ms, note Settings of the Delay C
The parameters are the same as for
the Delay L.
8 Delay Center 0 - 127 1-2540 ms
9 Delay Center 0 - 21 note
10 Center
Feedback #1
49 - 89 0- +80 % Adjusts the amount of the delay
sound that’s fed back into the effect.
11 HF Damp 0 - 17 200-8000 Hz,
Bypass
Adjusts the frequency above which
sound fed back to the effect is filtered
out. If you do not want to filter out
any high frequencies, set this
parameter to Bypass.
12 Left Level 0 - 127 0-127 Volume of each delay
13 Right Level 0 - 127 0-127 Volume of each delay
14 Center Level 0 - 127 0-127 Volume of each delay
15 Low Gain 0 - 30 -15- +15 dB Gain of the low frequency range
16 High Gain 0 - 30 -15- +15 dB Gain of the high frequency range
17 Balance #2 0 - 100 D100:0W-
D0:100W
Volume balance between the direct
sound (D) and the delay sound (W)
18 Level 0 - 127 0-127 Output level
No Parameter Value Description
1 Delay Left
Mode
0 - 1 ms, note When this is set to “note,” the effect is
synchronized with the tempo.
2 Delay Left 0 - 127 1-2540 ms Adjusts the delay time from the
direct sound until the delay sound is
heard. (Hz)
3 Delay Left 0 - 21 note Adjusts the delay time from the
direct sound until the delay sound is
heard. (note)
4 Delay Right
Mode
0 - 1 ms, note Settings of the Delay R
The parameters are the same as for
the Delay 1.
5 Delay Right 0 - 127 1-2540 ms
6 Delay Right 0 - 21 note
7 Delay Center
Mode
0 - 1 ms, note Settings of the Delay C
The parameters are the same as for
the Delay 1.
8 Delay Center 0 - 127 1-2540 ms
9 Delay Center 0 - 21 note
10 Center
Feedback #1
49 - 89 0- +80 % Adjusts the proportion of the delay
sound that is fed back into the effect.
11 HF Damp 0 - 17 200-8000 Hz,
Bypass
Adjusts the frequency above which
sound fed back to the effect will be
cut. If you do not want to cut the high
frequencies, set this parameter to
Bypass.
12 Left Level 0 - 127 0-127 Output level of the delay sound
13 Right Level 0 - 127
14 Center Level 0 - 127
15 Output Mode 0 - 1 Speaker,
Phones
Adjusts the method that will be used
to hear the sound that is output to the
OUTPUT jacks. The optimal 3D effect
will be achieved if you select
Speaker when using speakers, or
Phones when using headphones.
16 Low Gain 0 - 30 -15- +15 dB Gain of the low range
17 High Gain 0 - 30 -15- +15 dB Gain of the high range
18 Balance #2 0 - 100 D100:0W-
D0:100W
Volume balance between the direct
sound (D) and the effect sound (W)
19 Level 0 - 127 0-127 Output Level
