15
GW-7
PARTS LIST
fig.part1e
CASING
#
03786667 BOTTOM CASE 1
# 03897445 DISPLAY COVER 1
# 03897456 PANEL SHEET L 1
# *03897467 PANEL SHEET R FOR CHINA 1
# *03903212 PANEL SHEET R EXCEPT FOR CHINA 1
# 03786656 TOP CASE 1
* PANEL SHEET R is different between China version and others.
KNOB,BUTTON
#
03787089 R-KNOB SF BY MOONPO 3
# 03787090 R-KNOB LF BY MOONPO 1
12499175 BUTTON JSPUE001A 1
SWITCH
02891789 TACT SWITCH SKRGADD010 H=5.0 SW1,SW2,SW7,SW8,SW13,SW14,SW19,SW
20,SW24,SW25,SW29,SW30,SW34,SW35,S
W39,SW40 on PANEL L BOARD,
SW3,SW4,SW5,SW6,SW9,SW10,SW11,SW1
2,SW15,SW16,SW17,SW18,SW21,SW22,SW
23,SW26,SW27,SW28,SW31,SW32,SW33,S
W36,SW37,SW38,SW41,SW42,SW43,SW44
on PANEL R BOARD
44
01676512 PUSH SWITCH SDKLA10200 SW2 on MAIN BOARD 1
JACK,EXT TERMINAL
02781189 USB CONNECTOR YKF45-0021 JK4 on MAIN BOARD 1
00569278 6.5MM JACK LGR4609-7100 JK2,JK3,JK5,JK6,JK8 on MAIN BOARD 5
13449720 DC JACK HEC2305-01-250 JK7 on MAIN BOARD 1
02568867 MIDI JACK DIN HDC-052A-12 JK1 on MAIN BOARD 1
DISPLAY UNIT
#
03902867 UCZ24080 LCD UNIT 1
NOTE: Replacement UCZ24080 should be made on a unit base.
BENDER UNIT
03234723 PB-H0204 BENDER BY MOONPO 1
NOTE: Replacement PB-H0204 should be made on a unit base.
KEYBOARD ASSY
#
03903223 FOR SERVICE KEYBOARD ASSY 1
NOTE: See ‘KEYBOARD PARTS LIST’ for details.
PWB ASSY
#
*03891745 MAINBOARD ASSY FOR SERVICE FOR CHINA 1
# *03903234 MAINBOARD ASSY FOR SERVICE EXCEPT FOR CHINA 1
NOTE: ‘MAINBOARD ASSY’ includes the following parts.
12199584 GROUNDING TERMINAL M1698 TER1,TER2,TER3,TER4 on MAIN BOARD 4
# 03891756 PANEL L BOARD ASSY FOR SERVICE 1
NOTE: ‘PANEL L BOARD ASSY’ includes the following parts.
03671756 DS-KEY TOP SX2H-B GRS BY MOONPO 3+
3/2
03671767 NS-KEY TOP MX1H BY MOONPO 5
01783923 N S-KEYTOP MD1H 2
02230578 LED SPACER LDS-50R 1
12169368 LED SPACER LDS-40B 1
# 03891767 PANEL R BOARD ASSY FOR SERVICE 1
NOTE: ‘PANEL R BOARD ASSY’ includes the following parts.
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
NOTE: The parts marked # are new. (initial parts)
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
The description "Q'TY" means a necessary number of the parts per one product.
