HP-1 MH/RW, HP-2e RW/LA
Mar, 2002
15
01452189 COND. ECKDBE472 ZF C101on PAB 1
INDUCTOR, COIL, FILTER
<<EMI>> 12449326 NOISE SUP. SBT-0460 L15 on PAB 1
<<EMI>> 13529187 NOISE SUP. ELKTR391CA FL1,2,3 on PAB 3
<<EMI>> 12449355 NOISE SUP. FBR07H850TB00 L1,2,3,4 on PAB/L18,19,22 on PHB 7
CRYSTAL, RESONATOR
00894034 X-TAL 16 MHZ MA-406 X1 on MB 1
00901912 X-TAL 24.576 MHZ MA-406 X2 on MB 1
FUSE, FUSE HOLDER
J2559123 FUSE 5X20 630MAL/250V SEMKO F1 on PRIMARY B - only for 230V/230VE 1
J2559104 FUSE 5X20 3.15AL/250V SEMKO F1, F2 on PAB 2
12199597RI FUSE HOLDER T.P1 on PRIMARY B / on PAB 6
CONNECTOR
13369689RI 20P FEM. CONNECTOR AMP 1.27 CN5,6 on MB 2
J3439112 2P MALE CONNECTOR P 2.5 M CN16 on PHB 1
J3439120 4P MALE CONN. P.2 M CN4 on MB 1
J3439122 8P MALE CONNECTOR P.2 M CN16 on PAB 1
J3439141 10P MALE CONNECTOR P.2 M CN3 on MB 1
J3439124 10P MALE CONN. P. 2 M 90° CN3 on CB 1
J3439138 4P MALE CONNECTOR P 3.96 M CN5 on PAB 1
J3439147 14P MALE CONNECTOR P.2 M CN4 on PAB/CN8 on MB 2
J3439148 7P MALE CONNECTOR P.2 M CN2 on MB/CN6,9 on PAB/CN15 on PHB 4
13369898 2P MALE CONNECTOR B2P3-VH CN1,2 on PB 2
J3439152 5P MALE CONNECTOR P.3.96 M CN5 on PAB 1
J3439171 4P MALE CONNECTOR 90° P.2 M CN1 on CB 1
J3439172 8P MALE CONNECTOR 90°P.2 M CN4 on CB 1
WIRING, CABLE
K3468212 2P CABLE (18) (W/2PC) From CN16 on PHB to CN1 on LEDB. 1
K3468153 20P FLAT CABLE (52) -2C From CN6 on MB to CN KEY DX 1
K3468213 20P FLAT CABLE (72) -2C D/R From CN5 on MB to CN KEY SX 1
J3469143 1P CONN. AWG18 (10) -GREEN On PHB 1
7770122000 4P CABLE ASSY (32) 2C P.2 D/R From CN1 on CB to CN4 on MB 1
# 7773004000 4P CABLE ASSY (76/40) 1C P3.96 From CN5 on PAB to SPEAKERS 1
7699409000 7P CABLE ASSY (86) -2C P.2 From CN9 on PAB to CN15 on PHB 1
7711512000 7P CABLE ASSY (28) -2C P.2 D/R From CN6 on PAB to CN2 on MB 1
# 7773005000 8P CABLE ASSY (86) -2C P.2 D/R From CN4 on CB to CN1 on PAB 1
7699418000 10P CABLE ASSY (38) -2C P.2 From CN3 on CB to CN3 on MB 1
7700124000 14P CABLE ASSY (28) -2C P.2 From CN4 on PAB to CN8 on MB 1
TRANSFORMER
# K2458148 TRANSFORMER 100-240 HP-2E-RW 1
AC INLET
J3449103 UNIVERSAL AC INLET ON PCB on PB 1
SCREW
J2289101 SELF TAP.SCREW 2.9X 6 TC TC 2
J2289102 SELF TAP.SCREW 2.9X10 TC TC 8
J2289116 SELF TAP.SCREW 3.5X13 TC TC 6
J2289213 SELF TAP.SCREW 3.9X16 TC TC 12
J2289125 SCREW 2.9X10 TC TC PR TROP 4
J2289130 SCREW 2.9X13 TC TC PR TROP 7
J2289118 SCREW 2.9X16 TC TC PR BRUN 3
J2289212 SCREW 3.5X10 TC TC PR BRUN 6
J2289108 SELF LOCK.SCREW M3X10 TCTC H.6 3
J2289147 SELF LOCK.SCREW M3X12 TCTC H.6 5
J2289221 SELFLOCK. SCREW M4X10 TC TC TFR 9.5 6
J2289110 SELF LOCK.SCREW M4X20 TCTC H. 9.5 10
K2288110 SCREW M5X20 TC TC TFR H9.5 BRUN 8
J2289142 PITCH SCREW M5X25 TC TC 3
J2289193 SELF LOCK.SCREW M3X6 TC TC H.6 12
J2289135 SELF LOCK.SCREW M4X 7 TCTC T.8 4
J2289115 SCREW 3.5X9.5 TC PR TFR H.8 18
J2289227 SCREW 3.9X20 TC PR TFR T.8 BLACK PLATED 10
J2289150 SCREW 2.9X16 TC PR TFR H.7 17
K2288107 SCREW 3.9X13.5 TC PR TFR H.8 44
PACKING
# K2638266 RIGHT LDPE END SIDE + BOX HP-2E-RW 1
# K2638267 LEFT LDPE END SIDE + BOX HP-2E-RW 1
# K2638268 CENTRAL LDPE PROTECTION HP-2E-RW 2
K2678121 CARTENE HD ENVELOPE CM 80X200 1
K2678106 POLYETH.ENVELOPE 4OX55 1
# K2618266 OUTER CARTON HP-2E-RW 1
MISCELLANEOUS
40016756 NUT M12 HLJ0999-01-360 M12 2
J2289113 NUT 3MA H.3 2
J2329105 HINGE F/MUSIC REST 2
J2139114 FLAT WASHER I/D 5X14 TH. 1 8
K2168113 LED SPACER H. 17.1 E.D. 6.7 1
# K2168121 LED SPACER H. 3.6 D.E.9 6
# K2168122 LED SPACER H.4.6 D.E.5.5 12
K2268158 REST RUBBER NAIL F/LID 1
J2369106 WIRE HOLDER CLAMPING RN04 5
K2248160 AC SOCKET HOLDER 1
K2268121 RED FELT MM 1250X12X1.5 1
K2268127 BLACK ADH. FELT 1320X9X2.5 MM. 1
K2268149 ADHESIVE BLACK FELT MM540X15X1 2
K2268159 CUSHION F/LID BLIND 2
7695813000 VARNISHED WOOFER NET 2
K1188132 KEYBOARD SUPPORT R178 3
K253810302 FUSE WARNING LABEL 1
# K2128130 RIGHT GUIDE FOR SLIDE LID HP-2e-RW 1
# K2128131 LEFT GUIDE FOR SLIDE LID 1
# K2128132 SUPPORT F/SHAFT STAY HP-2E-RW 3
# K2128133 LID GEAR 2
# K2128134 COUPLING PIN F/TOP CBNT-REAR PANEL 3
# K2128135 COUPLING PIN FOR TOP CBNT 2
# K2148115 STOP PIN F/MUSIC SCORE HOLDER 2
ACCESSORIES
J3439155 CABLE CEE XVIIG-H05VVF2X1-C17W (230V) 1
J3439154 CABLE GB BS89/5 H05VV-F3G1 C13W (230VE) 1
J3439167 CABLE SAA/2-H05VV5 2X1-C17W (240VA) 1
# K6018467 OWNER'S MANUAL (E-D-F-IT-SP-OL) HP-2E 1
A 02892389 SONG BOOK 60 PCN 1
PARTS LIST STAND KS-2e-RW/LA
K3418105 CABLE F/PEDAL (84) KS-137/237/147 1
K2288109 SCREW 3.9X30 TC PR TFR T.8 BRUN 4
J2289208 SCREW 3.5X25 TC PR TFR H.8 BRUN 7
J2289247 SCREW M6X30 TC PHILIPS TBL 2
# J2289249 SCREW 4.5X45 TC PR TFR T.9.5 6
J2329107 JOINT BOLT ASSY 6
J2329101 SCREW DRIVER TYPE 2 1
K2358102 SIDE PANEL FOOT 2
K2128128 COUPLING BASE KS-237PE 2
K2638142 MID POLYST. END-SIDE 1
K2638143 POLYST. SHEET 500X1510X20 1
K2678115 CARTENE ENVELOPE HD 60X80 2
K2678116 CARTENE ENVELOPE HD 70X190 1
K2678102 POLYETH. ENVELOPE 25X45 1
K2678105 CARTENE ENVELOPE HD 140X57 1
# 7896601000 RIGHT SIDE PANEL ASSY KS-2E 1
# 7896602000 LEFT SIDE PANEL ASSY KS-2E 1
K1138111 BASE FOR PEDAL (MDF) KS-147E 1
# K1148148 REAR PANEL KS-2E/KS-3E/KS7E 1
# K2618267 OUTER CARTON KS-2E 1
J3059116 3-NOTE PEDAL KS-237E/147E 1
# K6018468 MOUNTING SCHEME KS-2E 1
ONLY FOR KS-2e LA
J2289248 SCREW M6X30 TC PHILIPS TBL 2
K2128129 COUPLING BASE KS-237LE 2
# 7897001000 RIGHT SIDE PANEL ASSY (OAK) KS-2E-LA 1
# 7897002000 LEFT SIDE PANEL ASSY (OAK) KS-2E-LA 1
# K1148151 REAR PANEL (OAK) KS-2E-LA 1
# 7897004000 BASE F/PEDAL ASSY KE-2E-LA 1
# 7897003000 FOOT F/SIDE PANEL (STAND) KS-2E-LA 2
NOTE: The “3-NOTE PEDAL KS-237” includes the parts shown in the Pedal Exploded view, on page 8..
