Roland HP-1 Service Notes

7
HP-1 MH/RW, HP-2e RW/LA
Mar, 2002
STAND EXPLODED VIEW HP-1-RW/MP
2
6
C
5
4
B
B
A
A
1
4
7
8
No. Part No. Description
1 7772905000 RIGHT SIDE PANEL (ROSEWOOD) HP-1-RW
7774402000 RIGHT SIDE PANEL (MAHOGANY) HP-1-MH
2 7772907000 LEFT SIDE PANEL (ROSEWOOD) HP-1-RW
7774403000 LEFT SIDE PANEL (MAHOGANY) HP-1-MH
3 7772906000 REAR PANEL (ROSEWOOD) HP-1-RW
7774401000 REAR PANEL (SATIN MAHOGANY) HP-1-MH
4 K235810101 FOOT F/SIDE PANEL KS-136
5 K2028143 COVER FOR PEDAL HP-1-RW
6 J2329107 JOINT BOLT ASSY
7 J3059113 2-NOTE PEDAL KS-137
8 J2329101 SCREW DRIVER TYPE 2
A J2289249 SCREW 4.5X45 TC PR TFR T.9.5
B J2289227 SCREW 3.9X20 TC PR TFR T.8 BLACK PLATED
C K2288107 SCREW 3.9X13.5 TC PR TFR H.8
3
No. Part No. Description
1
4
J3059114 RIGHT PEDAL (GOLD)
2
5
3
6
J2269108
K3418105
7625920000
J2289128
J2289125
RUBBER DAMPER FOR PEDAL
CABLE FOR PEDAL(84)
1P CONDUCTIVE RUBBER LR13/1
SELF.TAP SCREW 3,5x19 TCTCPRBZ
SCREW 2,9x10 TCTC PR TROP
7
8
A
B
K2918155
J2289190
PCB FOR PEDAL
BLACK KNOB M8x14
J3059115
J2179112
LEFT PEDAL (GOLD)
PEDAL SPRING 1,4x14x29
1
4
4
A
B
A
5
6
7
8
8
3
2
TP1
TP
TP3
TP
TP4
TP
TP5
TP
TP6
TP
WIR1
PEDAL CABLE
4 5 2
13
67
8 10 9
SW3
SW
SPST
1 2
SW1
SW
SPST
1 2
C1
0.1C
D
OFF
ON ON
OF
F
BRWN
ORNG
BLCK
BRWN
RED
ORNG
BLCK
SHLD
SHL
D
SOFT DAMPER
PEDAL BOARD 2 PEDALS
X
X
X
X
Circuit Diagram 2-Note Pedal
2-Note Pedal Exploded View & Parts List
ASSY J3059113
