HP-335 Nov.1998
4
00900512 PANEL HOLDER R
00900467 PWB HOLDER
12339355 SWITCH COVER 721128-18
22245194 POT DUST COVER M 1H
# 01346401 ISOLATOR LED SPONGE
22145199 SHAFT STAY L
22145901 SHAFT STAY R
01011390 SHAFT CUSHION
00900567 PANEL HOLDER FP
# 01344467 SW HOLDER
00900534 BRACKET
01011312 ISOLATOR LED SPONGE
KNOB,BUTTON
22495576 A S-BUTTON LX BLK POWER SWITCH
22495278 D S-KEYTOP MD2H BLK
00900145 D S-KEYTOP SD1H BLK
00900156 D S-KEYTOP SD2H BLK
00900167 D S-KEYTOP SD3H BLK
00900178 D S-KEYTOP SD4H BLK
00900189 D S-KEYTOP SX1H BLK
00904245 D S-KEYTOP SX3H BLK
22485192 I S-KNOB S BLK/LCG
SWITCH
13129139 SDDLB1-A-D-2 TV-5 5A/250V AC PUSH SWITCH
13169752 EVQ 213 05R TACT SWITCH SW1,3-10,12,13,15-17 on PLB/SW1,3-12 on PRB
13159363 SSSF124-S09N-1 SLIDE SWITCH SW301 on FJB
JACK,SOKET
13429911 TCS7927-28-401 DIN SOCKET JK304 on FJB
00340223 YKF51-5031 DIN SOCKET JK5 on PAB
13449283 HLJ7101-01-3010 JACK JK1-4 on PAB
13449252 YKB21-5006 JACK JK1 on MIC/JK301,302 on FJB
13429672 YKF51-5047 MIDI JK303 on FJB
13429676 YKF51-5048 MIDI JK6 on PAB
SPEAKER
01349778 PD-20103A3 FULL-RANGE
NOTE : For details, please refer to KEYBOARD PARTS LIST (page 10).
KEYBOARD ASSY
# 71017401 PA-4A88-C2 KEYBOARD ASSY
PCB ASSY
# E 71013190 MAIN BOARD ASSY
# 71011834 PANEL R BOARD ASSY
NOTE : PANEL R BOARD ASSY includes the following parts.
# 12169390 LED SPACER LH-36-4 on PRB
# 01450001 WIRING 14X120-P2.0-51065-51015-F on PRB
# 01450012 WIRING 15X180-P2.0-51065-51015-F on PRB
71013490 PANEL L BOARD ASSY
NOTE : PANEL L BOARD ASSY includes the following parts.
# 01450023 WIRING 9X350-P2.0-51065-51015-F on PLB
# 01450034 WIRING 12X400-P2.0-51065-51015-F on PLB
# 01450045 WIRING 8X400-P2.0-51065-51015-F on PLB
# 71011856 PAB3 ANALOG PHANTOM
NOTE : PAB3 ANALOG PHANTOM includes the following PWBs.
******** PAB3 EQ BOARD
******** PAB3 ANALOG BOARD
PARTS LIST
CONSIDERATIONS ON PARTS ORDERING
When ordering any parts listed in the parts list, please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
10 22575241 Sharp key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or even
undelivered replacement.
Ex.
SAFETY PRECAUTION:
The parts marked
have safety-
related characteristics.
Use only listed parts for
replacement.
FJB : FRONT JACK BOARD
PAB : PAB ANALOG BOARD
MIC : MIC BOARD
PLB : PANEL L BOARD
PRB : PLB PANEL R BOARD
MB : MAIN BOARD
EB : EQ BOARD
IB : INLET BOARD
NOTE : The part marked # are new (initial parts).
CASING
# 01344378 TOP BOARD
00900401 MUSIC REST
22325182 MR HINGE ASSY
00900278 MUSIC STOPPER
# 01344389 LID BOARD
00900378 LID BLIND CAP
01017678 LID BLIND
00900312 BLIND UPPER
# 01344445 REAR PANEL
# 01344390 FRONT PANEL
32225353 I S-ESCT SX1V BLK L=30
00341778 KEY FELT
# 01344589 DISPLAY COVER
# 01455767 END BLOCK L
# 01455778 END BLOCK R
00900501 SIDE PLATE L
00900523 SIDE PLATE R
00121945 SPEAKER COVER
00890990 ROLAND BADGE 12 GOLD
# 71011990 BOTTOM BOARD
NOTE : BOTTOM BOARD includes the following parts.
00569156 CUSHION T1*25*1200
01011534 CUSHION
# 71012023 SIDE PANEL L ASSY
NOTE : 'SIDE PANEL L ASSY' includes the following parts.
******** SIDE PANEL L
00900101 SIDE PANEL UPPER L
# 71012034 SIDE PANEL R ASSY
NOTE : 'SIDE PANEL R ASSY' includes the following parts.
******** SIDE PANEL R
00900123 SIDE PANEL UPPER R
# 71017734 BLIND ASSY
NOTE : 'BLIND ASSY' includes the following parts.
******** BLIND
# 01456034 SPACER BLIND D6×16.8
CHASSIS
01017134 LID RAIL STOPPER
00900356 LID ANGLE
00900390 LID SHAFT
22175664 LID GEAR
00900478 TOP BOARD HOLDER
00900289 CENTER HOLDER
00900490 PANEL HOLDER L
