16
MIDI Parameter Address Map
+------------------------------------------------------------------------------+
| Start | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 02 30 00 00 | Temporary Tone JD-800(01) [JD800] |
| 02 31 00 00 | Temporary Tone JD-800(02) [JD800] |
| : | |
| 02 33 00 00 | Temporary Tone JD-800(04) [JD800] |
|-------------+----------------------------------------------------------------|
* [JD800]
+------------------------------------------------------------------------------+
| Oset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 00 | Model JD-800 Parameter [JD800COM] |
|-------------+----------------------------------------------------------------|
| 00 01 00 | Model JD-800 Parameter Ptl 1 [JD800PTL] |
| 00 02 00 | Model JD-800 Parameter Ptl 2 [JD800PTL] |
| : | |
| 00 04 00 | Model JD-800 Parameter Ptl 4 [JD800PTL] |
|-------------+----------------------------------------------------------------|
| 00 05 00 | Model JD-800 Group A Eect [MFX](*) |
|-------------+----------------------------------------------------------------|
| 00 07 00 | Model JD-800 Group B Eect [JD800FxB] |
|-------------+----------------------------------------------------------------|
| 00 08 00 | Model JD-800 Tone Com [ToneCom](*) |
+------------------------------------------------------------------------------+
(*) See the “JUNO-X MIDI Implementation” for details.
* [JD800COM]
+------------------------------------------------------------------------------+
| Oset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0aaa aaaa | Level (0 - 100) |
| 00 01 | 0aaa aaaa | Key Range A Low (0 - 127) |
| 00 02 | 0aaa aaaa | Key Range A High (0 - 127) |
| 00 03 | 0aaa aaaa | Key Range B Low (0 - 127) |
| 00 04 | 0aaa aaaa | Key Range B High (0 - 127) |
| 00 05 | 0aaa aaaa | Key Range C Low (0 - 127) |
| 00 06 | 0aaa aaaa | Key Range C High (0 - 127) |
| 00 07 | 0aaa aaaa | Key Range D Low (0 - 127) |
| 00 08 | 0aaa aaaa | Key Range D High (0 - 127) |
| 00 09 | 00aa aaaa | Bender Range Down (0 - 48) |
| 00 0A | 0000 aaaa | Bender Range Up (0 - 12) |
| 00 0B | 000a aaaa | After Touch Bend Sens (0 - 26) |
| | | -36,-24,-12,-11,-10,-9,-8,-7,-6,-5,-4,-3,-2,-1, |
| | | 0,+1,+2,+3,+4,+5,+6,+7,+8,+9,+10,+11,+12 |
| 00 0C | 0000 000a | Solo Switch (0 - 1) |
| | | OFF, ON |
| 00 0D | 0000 000a | Solo Legato Switch (0 - 1) |
| | | OFF, ON |
| 00 0E | 0000 000a | Portamento Switch (0 - 1) |
| | | OFF, ON |
| 00 0F | 0000 000a | Portamento Mode (0 - 1) |
| | | NORMAL, LEGATO |
| 00 10 | 0aaa aaaa | Portamento Time (0 - 100) |
|# 00 11 | 0000 aaaa | |
| 00 12 | 0000 bbbb | EQ Mid Q (5 - 160) |
| | | 0.5 - 16.0 [EQQ] |
|# 00 13 | 0000 aaaa | |
| 00 14 | 0000 bbbb | |
| 00 15 | 0000 cccc | |
| 00 16 | 0000 dddd | EQ Low Frequency (20 - 16000) |
|# 00 17 | 0000 aaaa | |
| 00 18 | 0000 bbbb | |
| 00 19 | 0000 cccc | |
| 00 1A | 0000 dddd | EQ Mid Frequency (20 - 16000) |
|# 00 1B | 0000 aaaa | |
| 00 1C | 0000 bbbb | |
| 00 1D | 0000 cccc | |
| 00 1E | 0000 dddd | EQ High Frequency (20 - 16000) |
|# 00 1F | 0000 aaaa | |
| 00 20 | 0000 bbbb | |
| 00 21 | 0000 cccc | |
| 00 22 | 0000 dddd | EQ Low Gain (784 - 1264) |
| | | -24.0 - +24.0 [EQGAIN] |
|# 00 23 | 0000 aaaa | |
| 00 24 | 0000 bbbb | |
| 00 25 | 0000 cccc | |
| 00 26 | 0000 dddd | EQ Mid Gain (784 - 1264) |
| | | -24.0 - +24.0 [EQGAIN] |
|# 00 27 | 0000 aaaa | |
| 00 28 | 0000 bbbb | |
| 00 29 | 0000 cccc | |
| 00 2A | 0000 dddd | EQ High Gain (784 - 1264) |
| | | -24.0 - +24.0 [EQGAIN] |
| 00 2B | 0000 000a | EQ Switch (0 - 1) |
| | | OFF, ON |
| 00 2C | 0000 000a | Unison Switch (0 - 1) |
| | | OFF, ON |
|-------------+----------------------------------------------------------------|
| 00 00 00 2D |Total Size |
+------------------------------------------------------------------------------+
* [JD800PTL]
+------------------------------------------------------------------------------+
| Oset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 000a | Layer Partial Switch (0 - 1) |
| | | OFF, ON |
| 00 01 | 0000 000a | Active Partial Switch (0 - 1) |
| | | OFF, ON |
| 00 02 | 0000 00aa | Velocity Curve (0 - 3) |
| | | 1 - 4 |
| 00 03 | 0000 000a | Hold Control Switch (0 - 1) |
| | | OFF, ON |
| 00 04 | 0000 0aaa | LFO1:Waveform (0 - 4) |
| | | TRI, SAW, SQU, S&H, RND |
| 00 05 | 0000 000a | LFO1:Rate sync (0 - 1) |
| | | OFF, ON |
| 00 06 | 0aaa aaaa | LFO1:Rate (0 - 100) |
| 00 07 | 000a aaaa | LFO1:Rate nt (0 - 22) |
| | | 1/64T, 1/64, 1/32T, 1/32, 1/16T, 1/32., 1/16, |
| | | 1/8T, 1/16., 1/8, 1/4T, 1/8., 1/4, 1/2T, 1/4., |
| | | 1/2, 1T, 1/2., 1, 2T, 1., 2, 4 |
| 00 08 | 0aaa aaaa | LFO1:Delay time (0 - 101) |
| 00 09 | 0aaa aaaa | LFO1:Fade time (14 - 114) |
| | | -50 - 50 |
| 00 0A | 0000 00aa | LFO1:Oset (0 - 2) |
| | | -, 0, + |
| 00 0B | 0000 000a | LFO1:Key trig (0 - 1) |
| | | OFF, ON |
| 00 0C | 0000 0aaa | LFO2:Waveform (0 - 4) |
| | | TRI, SAW, SQU, S&H, RND |
| 00 0D | 0000 000a | LFO2:Rate Sync (0 - 1) |
| | | OFF, ON |
| 00 0E | 0aaa aaaa | LFO2:Rate (0 - 100) |
| 00 0F | 000a aaaa | LFO2:Rate nt (0 - 22) |
| | | 1/64T, 1/64, 1/32T, 1/32, 1/16T, 1/32., 1/16, |
| | | 1/8T, 1/16., 1/8, 1/4T, 1/8., 1/4, 1/2T, 1/4., |
| | | 1/2, 1T, 1/2., 1, 2T, 1., 2, 4 |
| 00 10 | 0aaa aaaa | LFO2:Delay Time (0 - 101) |
| 00 11 | 0aaa aaaa | LFO2:Fade time (14 - 114) |
| | | -50 - 50 |
| 00 12 | 0000 00aa | LFO2:Oset (0 - 2) |
| | | -, 0, + |
| 00 13 | 0000 000a | LFO2:Key trig (0 - 1) |
| | | OFF, ON |
|# 00 14 | 0000 aaaa | |
| 00 15 | 0000 bbbb | |
| 00 16 | 0000 cccc | |
| 00 17 | 0000 dddd | WG:Waveform (0 - 108) |
| 00 18 | 0000 0000 | Reserved (0 - 0) |
| 00 19 | 0000 0aaa | WG:Wave gain (0 - 5) |
| | | -18, -12, -6, 0, +6, +12[dB] |
| 00 1A | 0aaa aaaa | WG:Pitch coarse (16 - 112) |
| | | -48 - 48 |
| 00 1B | 0aaa aaaa | WG:Pitch ne (14 - 114) |
| | | -50 - 50 |
| 00 1C | 0aaa aaaa | WG:Pitch random (0 - 100) |
| 00 1D | 000a aaaa | WG:Pitch KF (0 - 16) |
| | | -100, -50, -20, -10, -5, 0, +5, +10, +20, +50, |
| | | +98, +99, +100, +101, +102, +150, +200[%] |
| 00 1E | 0000 000a | WG:Bender Sw (0 - 1) |
| | | OFF, ON |
| 00 1F | 0000 000a | WG:Atch bend sw (0 - 1) |
| | | OFF, ON |
| 00 20 | 0aaa aaaa | WG:LFO1 depth (14 - 114) |
| | | -50 - 50 |
| 00 21 | 0aaa aaaa | WG:LFO2 depth (14 - 114) |
| | | -50 - 50 |
| 00 22 | 0aaa aaaa | WG:Lever sens (14 - 114) |
| | | -50 - 50 |
| 00 23 | 0aaa aaaa | WG:Atch msens (14 - 114) |
| | | -50 - 50 |
| 00 24 | 0aaa aaaa | Pitch Env Velocity Sens (14 - 114) |
| | | -50 - 50 |
| 00 25 | 0aaa aaaa | Pitch Env Time Velocity Sens (14 - 114) |
| | | -50 - 50 |
| 00 26 | 0aaa aaaa | Pitch Env Time Keyfollow (54 - 74) |
| | | -10 - 10 |
| 00 27 | 0aaa aaaa | Pitch Env L0 (14 - 114) |
| | | -50 - 50 |
| 00 28 | 0aaa aaaa | Pitch Env L1 (14 - 114) |
| | | -50 - 50 |
| 00 29 | 0aaa aaaa | Pitch Env L2 (14 - 114) |
| | | -50 - 50 |
| 00 2A | 0aaa aaaa | Pitch Env T1 (0 - 100) |
| 00 2B | 0aaa aaaa | Pitch Env T2 (0 - 100) |
| 00 2C | 0aaa aaaa | Pitch Env T3 (0 - 100) |
| 00 2D | 0000 00aa | TVF:Filter mode (0 - 2) |
| | | LPF, BPF, HPF |
| 00 2E | 0aaa aaaa | TVF:Cuto freq (0 - 100) |
| 00 2F | 0aaa aaaa | TVF:Resonance (0 - 100) |
| 00 30 | 00aa aaaa | TVF:Cuto KF (0 - 40) |
| | | -100, -90, -80, -70, -60, -50, -40, -30, -20, -10, |
| | | 0, +5,+10, +15, +20, +25, +30, +35, +40, +45, +50, |
| | | +55, +60, +65, +70, +75, +80, +85, +90, +95, +100, |
| | | +105, +110, +115, +120, +125, +130, +135, +140, |
| | | +145 ,+150[%] |
| 00 31 | 0aaa aaaa | TVF:Atch sens (14 - 114) |
| | | -50 - 50 |
| 00 32 | 0000 000a | TVF:LFO select (0 - 1) |
