Roland JUNO-X User Manual

6
Using the JD-800 Model Expansion
Selecting a Tone
1. Press the [MODEL BANK] button.
The MODEL BANK top screen appears.
Model/category
Model name/category name
Tone number
Tone name
2. Use the [
Ç
SELECT
É
] knob to move the cursor to the
model name/category name.
3. Use the [- VALUE +] knob to select “JD-800”.
4. Use the [
Ç
SELECT
É
] knob to move the cursor to the
tone number.
5. Use the [- VALUE +] knob to select the tone.
MEMO
Move the cursor to the model name/category name or the tone
number and press the [ENTER] (INIT) button. The tone list appears.
6. Press the [ENTER] (INIT) button to select the tone.
Registering the JD-800 to a model bank
1. Hold down the [MODEL BANK] button and press a
model bank button ([1]–[16]).
2. Use the [
Ç
SELECT
É
] knob to move the cursor to
“Attr”.
3. Use the [- VALUE +] knob to select “MODEL”.
4. Use the [
Ç
SELECT
É
] knob to select where to
register the JD-800.
5. Use the [- VALUE +] knob to select “JD-800”.
6. If you want to save the setting, execute the System
Write operation.
6-1.
Hold down the [SHIFT] button and press the [MENU] (WRITE)
button.
The WRITE MENU screen appears.
6-2.
Use the [
Ç
SELECT
É
] knob to select “SYSTEM”, and then press
the [ENTER] (INIT) button.
6-3.
To execute, press the [ENTER] (INIT) button.
Selecting a JD-800 tone using the model bank
1. Press the [MODEL BANK] button.
The MODEL BANK top screen appears.
Use the [1]–[16] buttons to switch to tone select mode.
2. Select the model bank where you registered the
JD-800 by pressing one of the [1]–[16] buttons.
The tones for the JD-800 are shown.
You can use the [- VALUE +] knob to select a tone on this screen as
well.
3. Press the [ENTER] (INIT) button.
A list of tones is shown.
4. Use the [- VALUE +] knob to select the tone.
You can use the [
Ç
SELECT
É
] knob to select the tone quickly.
5. Press the [ENTER] button.
The tone is now selected.

Roland JUNO-X Specifications

Keyboard Specifications

keyboard keys	61 keys
preset tone	4000 or greater
user tone	256

Effects and Sound Generators

multi-effects systems	4 systems
multi-effects types	93 types
reverb types	8 types

Bluetooth and Display

bluetooth profile support	A2DP (Audio), GATT (MIDI over Bluetooth Low Energy)
codec	SBC (Support to the content protection of the SCMS-T method)
display resolution	128 x 64 dots

Speakers and Amplifiers

speaker amplifier power	4W x 2
full range speakers	3.5 x 8 cm x 2
tweeter size	2 cm x 2

Connectors and Ports

headphones jack	Stereo miniature phone type (front), Stereo 1/4-inch phone type (rear)
main out jacks	1/4-inch phone type, XLR type
mic input jack	1/4 inch phone type/XLR type

Weight and Dimensions

dimensions	1072 (W) x 333 (D) x 118 (H) mm
weight	11.6 kg
power consumption	20 W
