Connections
Connect the included AC adaptor to the SONAR V-STUDIO 100’s DC IN jack.
fig.Connect-ACadpt.eps
Place the AC adaptor so the side with the indicator (see illustration) faces upwards and the side with textual
information faces downwards.
* The indicator will light when you plug the AC adaptor into an AC outlet.
To prevent the inadvertent disruption of power to your unit (should the plug be pulled out accidentally), and to
avoid applying undue stress to the AC adaptor jack, anchor the power cord using the cord hook, as shown in
the illustration.
fig.CordHook.j.eps
Connecting the AC adaptor
DC IN
to Power Outlet
AC Adaptor
(included)
Power Cord
(included)
Indicator
Cord Hook
AC Adaptor Cord
