Roland V-Piano User Manual

23
Getting ready
1.
Before you switch off the power, turn the volume down all the way with the [VOLUME] Knob.
Also completely turn down the volume of any connected audio device and other equipment.
2.
Turn off the power to connected external devices.
3. Press the lower portion of the [POWER] switch on the back of the V-Piano.
The power is switched off.
If you need to turn off the power completely, first turn off the [POWER] switch, then unplug the power cord from the power
outlet. Refer to “Power Supply” (p. 7) .
1.
Adjust the volume using the [VOLUME] Knob.
Rotate the knob clockwise to increase the volume, or rotate it counterclockwise to lower it.
Also, adjust the volume of the connected device to an appropriate level.
The characters in the display may be difficult to view immediately after turning on the power or after extended use; this may also be
because of where and how the display is situated.
In such instances, adjust the contrast of the display by turning the [DISPLAY CONTRAST] Knob on the rear panel.
Turning off the power
Adjusting the volume
Adjusting the display’s contrast ([DISPLAY CONTRAST] Knob)
Rear Panel
V-Piano_e.book 23 ページ ２００９年１月２８日 水曜日 午前９時１０分

Roland V-Piano Specifications

General

Damper pedal	Yes
Sound effects	Ambience
Tones quantity	256
Pedals quantity	3
Built-in speaker(s)	No
Maximum polyphony (notes)	128
Keyboard name	PHA III
Keys quantity	88 keys
Equalizer bands quantity	4
Recorder/sequencer number of tracks	1
AC input voltage	100 - 220 V
AC input frequency	50 - 60 Hz
Power consumption (max)	27 W
Cables included	AC, USB
Display resolution	240 x 64 pixels
Product color	Black

Weight and Dimensions

Depth	530 mm
Width	1411 mm
Height	166 mm
Weight	38200 g
