Roland V-Synth GT Service Notes

13
May, 2007 V-SYNTH/GT
Exploded View (Fig.1) Parts List
No. Part Code Part Name Description Q’ty
1-1 04566312 DISPLAY ESCT 1
1-2 ******** POSITION SENSOR EMU601A2MA32 1
******** LCD TCG057QV1AC-G10 1
1-3 03897512 DISPLAY HOLDER B 2
1-4 04566434 DISPLAY HOLDER 1
1-5 73566345 SUB BOARD ASSY 1
No. Part Code Part Name Description Q’ty
a 40011101 SCREW 3X8 BINDING TAPTITE B BZC 8
