May, 2007 V-SYNTH/GT

Parts List

fig.part1e

SAFETY PRECAUTIONS:

The parts marked have

safety-related characteristics. Use

only listed parts for replacement.

NOTE: The parts marked # are new. (initial parts)

Due to one or more of the following reasons,

parts with parts code ******** cannot be supplied as service parts.

• Part supplied only as a component in a complete assembly

• Copyright does not permit the part to be supplied

• Part is sold commercially

The description "Q'TY" means a necessary number of the parts per one product.

CASING

# 04566923 J R-ESCT SX4H SLV 2

# 04566912 J R-ESCT SX3H SLV 2

# 04566489 J R-ESCT SX2H SLV 2

# 04566478 J R-ESCT SX1H SLV 6

# 04566290 BENDER PANEL 1

# 04566267 BOTTOM COVER 1

# 04566312 DISPLAY ESCT 1

# 04566301 END BLOCK 1

# 04566490 LED COVER 1

# 04566323 PAD ESCT 1

03126590 POT DUST COVER A 1

# 04566278 SIDE COVER L 1

# 04566289 SIDE COVER R 1

# 04563678 TOP PANEL 1

04344312 TWIN D-BEAM CONTROLLER

ESCT.

CHASSIS

01786045 SW HOLDER AT-217K 1

# 04671323 CHANNEL 1

# 04566434 DISPLAY HOLDER 1

03897512 DISPLAY HOLDER B 2

# 04566389 MAIN PWB HOLDER 1

# 04566378 PANEL PWB HOLDER 3

# 04566390 PWR SPLY HOLDER 1

# 04566334 SIDE HOLDER L 1

# 04566345 SIDE HOLDER R 1

KNOB, BUTTON

# 04565478 KNOB ZE R-KNOB LF 1

# 04566456 KEYTOP ZE CURSOR KEY B 1

# 04566445 KEYTOP ZE CURSOR KEY A 1

03120889 D S-KEYTOP SX2H-B GRS 18

03126856 D S-KEYTOP SX2H-B CLR 2

03120890 D S-KEYTOP SX1H-B GRS 12

03126867 D S-KEYTOP SX1H-B CLR 12

04124267 J R-KNOB SF-ELA BLK/SLV 23

01783956 N S-KEYTOP MD4H 2

22495278 DS-KEYTOP MD2H BLK (W/WINDOW) 1

04347467 J R-KNOB ELA-ENC BLK/SLV 1

01561578 J S-KNOB S BLK/LCG 4

SWITCH

03016956 SLIDE SWITCH SSSU121700 SW1 on Jack Board 1

02781634 TACT SWITCH SKRGAED010 SW3, SW4 on Bender Board, SW8, SW7,

SW6, SW27, SW26, SW31, SW5, SW9, SW28,

SW25, SW30, SW11, SW32, SW36, SW35,

SW34, SW29, SW13, SW21, SW20, SW19,

SW18, SW17, SW16, SW23, SW14, SW4,

SW12, SW1, SW2, SW3, SW37, SW22, SW33,

SW24, SW15 on PANEL-L Board, SW10,

SW9, SW8, SW7, SW6, SW4, SW1, SW28,

SW23, SW24, SW25, SW11, SW27, SW3,

SW43, SW42, SW41, SW40, SW39, SW38,

SW37, SW36, SW35, SW34, SW33, SW30,

SW29, SW26, SW22, SW20, SW19, SW2,

SW21, SW18, SW12, SW17, SW16, SW15,

SW14, SW13 on PANEL-R Board

01786012 SEESAW SWITCH JW-M11RKK 1
