Roland V-Synth GT Service Notes

7
May, 2007 V-SYNTH/GT
Exploded View (Total) Parts List
No. Part Code Part Name Description Q’ty
1 04563678 TOP PANEL 1
2 04566290 BENDER PANEL 1
3 02673945 STAY BENDER 1
4 03234723 BENDER PB-H0204 1
5 22495278 DS-KEYTOP MD2H BLK (W/WINDOW) 1
6 04124267 J R-KNOB SF-ELA BLK/SLV 23
7 04347467 J R-KNOB ELA-ENC BLK/SLV 1
8 01561578 J S-KNOB S BLK/LCG 4
9 04566323 PAD ESCT 1
10 73459734 XY-PAD ASSY 1
11 73459789 PAD BOARD ASSY 1
12 04566490 LED COVER 1
13 04565478 KNOB ZE R-KNOB LF 1
14 04566456 KEYTOP ZE CURSOR KEY B 1
15 04566445 KEYTOP ZE CURSOR KEY A 1
16 04566378 PANEL PWB HOLDER 3
17 73459834 BENDER BOARD ASSY 1
18 ******** POWER SUPPLY ASSY 1
19 04566278 SIDE COVER L 1
20 04566334 SIDE HOLDER L 1
21 04566289 SIDE COVER R 1
22 04566345 SIDE HOLDER R 1
23 ???????? SK-1061-A KBD ASSY 1
24 04566267 BOTTOM COVER 1
25 12359139 RUBBER FOOT FF-018 BLK 4
26 04566301 END BLOCK 1
18-1 04671323 CHANNEL 1
18-2 04671301 SPACER KGPS-3S V0 1
18-3 04561723 SWITCHING REGULATOR LEA50F-5-SXRLD 1
18-4 04566390 PWR SPLY HOLDER 1
18-5 01455523 CORD BUSHING EDS-1717U 2
18-6 04671312 SPACER KGPS-10RF V0 2
a 40011101 SCREW 3X8 BINDING TAPTITE B BZC 2
c 40237101 SCREW M3X8 PAN MACHINE W/SW+SMALL PW BZC 4
