Roland VS-2400CD Service Notes

2
Jan.2003
SPECIFICATIONS
VS-2400CD: 24Tr,24bit,96kHzSampling Digital
Studion Workstation
• Tracks
Tracks:24
V-Tracks:384 (16 V-Tracks per each Track)
• Sample Rate
96.0 / 88.2 / 64.0 / 48.0 / 44.1 / 32.0 kHz
* Adjustable range with vari-pitch function
22.00kHz-98.00kHz (at 96kHz)
22.00kHz-50.00kHz (at 48kHz)
• Recording Mode
Mastering 24-bit (M24)
Multitrack Pro (MTP)
CD Writing (CDR)
Mastering 16-bit (M16)
Multitrack 1 (MT1)
Multitrack 2 (MT2)
Live 1 (LIV)
Live 2 (LV2)
• Maximum Simultaneous Recording / Playback Tracks
Sample Rate 48/44.1/32kHz
16 tr. Rec / 16 tr. Play (M24,M16,CDR)
16 tr. Rec / 24 tr. Play (MTP,MT1/2,LIV,LV2)
Sample Rate 96/88.2/64kHz
8 tr. Rec / 8 tr. Play (M24,M16,CDR)
8 tr. Rec / 12 tr. Play (MTP,MT1/2,LIV,LV2)
* Depending on the organization of the song data or the disk drive performance
etc., the number of tracks which can be simultaneously recorded or played back
may be limited.
• Maximum Useful Capacity
40 GB
• Recording Time
(at 10GB Partition, conversion in 1 track, unit : minutes)
Recording Mode Sample Rate
96kHz 88.2kHz 64kHz 48kHz 44.1kHz 32kHz
M24 662 721 993 1,324 1,442 1,987
MTP 1,989 2,165 2,983 3,977 4,329 5,966
M16 994 1,082 1,491 1,989 2,165 2,983
CDR 994 1,082 1,491 1,989 2,165 2,983
MT1 1,989 2,165 2,983 3,977 4,329 5,966
MT2 2,651 2,885 3,976 5,302 5,771 7,953
LIV 3,181 3,462 4,772 6,362 6,925 9,543
LV2 3,977 4,329 5,966 7,955 8,658 11,932
* The above-listed recording times are approximate. Times may be slightly
depending on the specifications of the disk drive and on the number of songs that
were created.
In “CDR” recording mode, two tracks are always used in a pair (channel link is
on), so recording time is half the above-listed.
• Frequency Response
96.0kHz : 20Hz - 40kHz (+0dB/-2dB)
88.2kHz : 20Hz - 40kHz (+0dB/-2dB)
48.0kHz : 20Hz - 22kHz (+0dB/-2dB)
44.1kHz : 20Hz - 20kHz (+0dB/-2dB)
32.0kHz : 20Hz - 14kHz (+0dB/-2dB)
• Songs
200 songs
• Marker
1000 per project
• Locator
100 (10 x 10 banks) per project
• Scene
100 (10 x10 banks) per project
• Undo/Redo
999 Undo / 1 Redo
• Nominal Input Level (variable)
Input 1-8 :-64 - +14dBu (maximum +26dBu : balanced, maximum
+20dBu : unbalanced)
Guitar (Hi-Z) :-64 - +14dBu (maximum +20dBu)
• Input Impedance
Input 1-8 : 40k ohm (balanced)
Guitar (Hi-Z) : 1M ohm
• Nominal Output Level
Master Out : +4dBu (balanced)
AUX A (L, R) : +4dBu (balanced)
AUX B (L, R) : +4dBu (balanced)
Monitor Out : +4dBu (balanced)
• Output Impedance
Master Out : 600 ohm
AUX A (L, R) : 600 ohm
AUX B (L, R) : 600 ohm
Monitor Out : 600 ohm
Phones : 22 ohm
• Recommended Load Impedance
Master Out : 10k ohm or greater
AUX A (L, R) : 10k ohm or greater
AUX B (L, R) : 10k ohm or greater
Monitor Out : 10k ohm or greater
Phones : 8 - 600 ohm
• Residual Noise Level
(input terminated with 1k ohm, INPUT SENS : LINE, IHF-A, typ.)
Master Out : -86dBu or less
AUX A : -86dBu or less
AUX B : -86dBu or less
Monitor Out : -86dBu or less
• EQ
4-band (2 shelving + 2 peaking)
* Useful simultaneously at up to 32ch in both Input Mixer and Track Mixer.
