4
Jan.2003
LOCATION OF CONTROLS PARTS LIST
[Parts]
No Part Code Part Name Description Q’ty
1 03121267 TOP COVER 1
2 03121278 SIDE PANEL L 1
3 03121289 SIDE PANEL R 1
4 03121334 REAR PANEL 1
5 03121323 DISPLAY ESCUTCHEON 1
6 03121290 DISPLAY COVER 1
7 01786012 SEESAW SWITCH JW-M11RKK 1
8 02563867 WIRING AC ASSY
9 02562956 DC FAN MOTOR 9A0812L403 1
10 13429825 MIDI CONNECTOR YKF51-5054 2PZ 1
11 01238856 CONNECTOR YKF42-8020 (TO PC DISPLAY OUT) 1
12 02455890 D-SUB CONNECTOR YKF42-8039 1
13 02565390 OPTICAL CONNECTOR TX GP1FA501TZ 1
14 02565401 OPTICAL CONNECTOR RX GP1FA501RZ 1
15 00458801 PIN JACK (ORG) PINx2 YKC21-3044 0/0 1
16 00569278 6.5MM JACK LGR4609-7100 10
17 03124956 DIN CONNECTOR YKF51-5399 2
18 02565389 U R-KNOB S1 LCG RED 1
03126412 9M/M ROTARY POT. RK09L1140 10KB L=25 1
19 02451189 VS KEYTOP SX PERPUL 1
02453834 PUSH SWITCH SPPH430100 1
20 01891834 U R-KNOB S1 LCG BLU 1
02901678 9M/M ROTARY POT. RK09L12D0 50KA L=25 1
21 01453123 XLR CONNECTOR NC3FAV2-0 8
22 01789234 6.5MM JACK JY-6353-01-250 9
23 01891801 U R-KNOB S1 LCG BLK 8
03124945 9M/M ROTARY POT. RK09L1140 50KRD L25 RR1 8
24 01904401 9M/M ROTARY POT. EVU F2A E25 B53 1
25 03121423 KEYTOP R 1
02891789 TACT SWITCH SKRGADD010 H=5.0 85
26 03121423 KEYTOP R 1
02891789 TACT SWITCH SKRGADD010 H=5.0 85
01239856 LED (ORANGE) SEL5921A TP15 54
27 03121412 KEYTOP L 1
02891789 TACT SWITCH SKRGADD010 H=5.0 85
03012001 LED SML72423C TP15 D RANK 12
28 22485303 D R-KNOB(ALPHA-DIAL) L BLK 248-303 1
01231367 ROTARY ENCODER EC16B24204 (L=15) (W/N&W) 1
29 00901390 KEYTOP STOP(WHIT GREY) 1
00894645 TACT SWITCH SKECAF WITHOUT LED 3
30 00901401 KEYTOP PLAY(WHIT GREY) 1
00894645 TACT SWITCH SKECAF WITHOUT LED 3
31 00901412 KEYTOP REC(RED) 1
00894645 TACT SWITCH SKECAF WITHOUT LED 3
32 03121423 KEYTOP R 1
03011990 LED (RED) SEL5221S TP15 D RANK 2
33 03121423 KEYTOP R 1
00676423 LED (GREEN) SEL5421E TP-15 2
34 01349423 U S-KNOB M1 LCG DCG GRY/BLK 12
02901734 60M/M MOTOR FADER EVANSA CB1 B14 13
35 01349434 U S-KNOB M1 MRD LCG 1
02901734 60M/M MOTOR FADER EVANSA CB1 B14 13
36 03121412 KEYTOP L 1
02891789 TACT SWITCH SKRGADD010 H=5.0 85
01239856 LED (ORANGE) SEL5921A TP15 54
37 03121423 KEYTOP R 1
01239856 LED (ORANGE) SEL5921A TP15 54
38 03231878 CD-R/RW DRIVE UJDA 360RL-Z 1
To Next Page
