Hardware Installation and Reference Guide Installing the Enterprise-class Router
17
3.2.1 Mounting into a Cabinet
Ruijie enterprise-class router products are designed based on the dimension of a standard cabinet. You can
install the device with the enclosed fixing accessories. You can install the device with the enclosed fixing
accessories by four M4 screws, length 8mm.
3.2.2 Mounting on a Workbench
In most cases, the user does not have a standard cabinet. Instead, the user can place the device on a clean
workbench. Although it is easy and simple, you shall pay attention to the following:
Guarantee the steadiness and good grounding of the workbench;
Stick the attached plastic pads onto the small holes at the bottom of the enterprise-class router, and reserve
a heat elimination room of at least 10 cm around the device. You can install the device with the enclosed
fixing accessories by four M4 screws, length 8mm.
Do not place heavy things on the device.
3.3 Installing Power Cables
The requirements of Ruijie RG-NBR-E series enterprise-class router products on AC power supply are described
below (refer to the section of “Product Overview” for detailed parameters):
100–240 V / 50/60 Hz
Make sure your power supply meets the requirement.
The router uses 3-conductor power cables. You are suggested to use a single-phase 3-conductor outlet or a
multifunction microcomputer outlet with neutral connector. The neutral point of the power supply shall be
securely grounded in the building. In most buildings, the neutral point of a power supply has been grounded
during the construction. You need to make sure the power supply is properly grounded.
Install power cables as per the following steps:
(1) Plug one end of the power cable into the power port on the backpanel of a enterprise-class router, and plug
the other end into the AC power supply outlet.
(2) Check whether the power LED on the front panel of the enterprise-class router lights up or not. The LED
indicator will light up if the power supply is properly connected.
(3) Make sure to ground the equipment by connecting grounding pole using the accessory green-yellow earthing
wire.
3.4 EMC Grounding
The grounding required for EMC design includes shielding ground, filter ground, noise and interference
suppression, and level reference. All the above constitute the comprehensive grounding requirements. The
grounding resistance should be less than 1 ohm. The RG-NBR-E series devices are equipped with a grounding
pole at the rear panel, as shown in Figure 3-2.
