Appendix B — Mini-GBIC Modules
Ruijie provide supporting SFP modules (Mini-GBIC modules) based on the port types of switch modules. You can select a module to
suit your specific needs. Besides, the Mini-GBIC-GT module is also supported. This document provides models and technical
parameters of some 1000 M SFP modules for reference. For details about the technical specifications, see Ruijie Transceiver
Installation and Reference Guide.
Table B-1 Models and Specifications of 1000 M Mini-GBIC (SFP) Optical Modules
Model
Wave Length (nm)
Media
Type
DDM
(Yes/
No)
Intensity of Transmitted
Light (dBm)
Intensity of Received
Light (dBm)
Min
Max
Min
Max
MINI-GBIC-SX-MM850
850
MMF
No
-9.5
-3
-17
0
MINI-GBIC-LX-SM1310
1310
SMF
No
-9.5
-3
-20
-3
GE-SFP-SX
850
MMF
No
-9.5
-3
-17
0
GE-SFP-LX
1310
SMF
No
-9.5
-3
-20
-3
GE-SFP-SX-SM1550-BIDI
1550TX/1310RX
MMF
No
-10
-5
-17
-3
GE-SFP-SX-SM1310-BIDI
1310TX/1550RX
MMF
No
-10
-5
-17
-3
GE-eSFP-SX-MM850
850
MMF
Yes
-9.5
-3
-17
0
GE-eSFP-LX-SM1310
1310
SMF
Yes
-9.5
-3
-20
-3
GE-SFP-LX-SM1310
1310
SMF
No
-9.5
-3
-20
-3
GE-SFP-LX20-SM1310-BIDI
1310TX/1550RX
SMF
Yes
-9
-3
-20
-3
GE-SFP-LX20-SM1550-BIDI
1550TX/1310RX
SMF
Yes
-9
-3
-20
-3
GE-SFP-LH40-SM1310-BIDI
1310TX/1550RX
SMF
Yes
-5
0
-24
-1
GE-SFP-LH40-SM1550-BIDI
1550TX/1310RX
SMF
Yes
-5
0
-24
-1
MINI-GBIC-LH40-SM1310
1310
SMF
Yes
-2
3
-22
-3
MINI-GBIC-ZX50-SM1550
1550
SMF
Yes
-5
0
-22
-3
MINI-GBIC-ZX80-SM1550
1550
SMF
Yes
0
4.7
-22
-3
MINI-GBIC-ZX100-SM1550
1550
SMF
Yes
0
5
-30
-9
Table B-2 Model of 1000 M SFP Copper Port Module
Standard
Model
DDM (Yes/No)
1000Base-T
Mini-GBIC-GT
No
Table B-3 Cabling Specifications of SFP Modules
Model
Interface
Type
Fiber Type
Core Size(μm)
Cable Distance (Max.)
MINI-GBIC-SX-MM850
LC
MMF
62.5/125
275 m
50/125
550 m
MINI-GBIC-LX-SM1310
LC
SMF
9/125
10 km
GE-eSFP-SX-MM850
LC
MMF
62.5/125
275 m
