Location No. Code No. Description Specification Q’TY SA/SNA Remark
MAIN PCB : DB93-04128A
6. Electrical Parts List
6-1
D101 0402-000137 DIODE-RECTIFIER 1N4007,1KV,1A,DO-41,TP 1 SNA
D102 0402-000137 DIODE-RECTIFIER 1N4007,1KV,1A,DO-41,TP 1 SNA
D103 0402-000137 DIODE-RECTIFIER 1N4007,1KV,1A,DO-41,TP 1 SNA
D104 0402-000137 DIODE-RECTIFIER 1N4007,1KV,1A,DO-41,TP 1 SNA
D105 0402-000137 DIODE-RECTIFIER 1N4007,1KV,1A,DO-41,TP 1 SNA
Q601 0501-000303 TR-SMALL SIGNAL KSA733,PNP,250mW,TO-92,TP,120-240 1 SNA
Q101 0501-000398 TR-SMALL SIGNAL KSC945-Y,NPN,250mW,TO-
92,TP,120-240
1 SNA
Q102 0501-000398 TR-SMALL SIGNAL KSC945-Y,NPN,250mW,TO-
92,TP,120-240
1 SNA
Q602 0501-000398 TR-SMALL SIGNAL KSC945-Y,NPN,250mW,TO-
92,TP,120-240
1 SNA
Q603 0501-000398 TR-SMALL SIGNAL KSC945-Y,NPN,250mW,TO-
92,TP,120-240
1 SNA
ICO1 1203-000243 IC-POSI.FIXED REG. 7812,TO-220,3P,-,PLASTIC,11.5/
12.5V,16W,0TO+125C,1A,-,ST,-
1 SNA
ICO2 1203-000429 IC-POSI.FIXED REG. 78L05A,TO-92,3P,-,PLASTIC,4.6/ 1 SNA
VA71
1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP 1 SNA
R103 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 SNA
R104 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 SNA
R105 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 SNA
R605 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 SNA
R606 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 SNA
R609 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 SNA
R610 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 SNA
R102 2001-000591 R-CARBON 3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 SNA
R608 2001-000734 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 SNA
R602 2001-000780 R-CARBON 470OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 SNA
R603 2001-000780 R-CARBON 470OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 SNA
R601 2001-000855 R-CARBON 560OHM,5%,1/4W,AA,TP,2.4X6.4MM 1 SNA
R101 2007-000290 R-CHIP 100ohm,5%,1/8W,TP,2012 1 SNA
R607 2007-000290 R-CHIP 100ohm,5%,1/8W,TP,2012 1 SNA
C107 2202-000128 C-CERAMIC,MLC-AXIAL 10nF,+80-20%,50V,Y5V,TP,2.5x4. 1 SNA
C108 2202-000128 C-CERAMIC,MLC-AXIAL 10nF,+80-20%,50V,Y5V,TP,2.5x4. 1 SNA
C102 2202-000780 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,-,3.5x19mm,- 1 SNA
C104 2202-000780 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,-,3.5x19mm,- 1 SNA
C106 2202-000780 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,-,3.5x19mm,- 1 SNA
CR71 2301-001363 C-FILM,LEAD-PPF 2000nF,+10-
5%,450V,BK,38x18x30mm,33
1 SNA
XC71 2301-001439 C-FILM,LEAD-PPF 220nF,10%,275V,BK,18x10x15.8mm,15 1 SNA
C101 2401-000173 C-AL 1000uF,20%,35V,GP,TP,13x25,5 1 SNA
C103 2401-000711 C-AL 2200uF,20%,25V,GP,TP,16x25,7.5 1 SNA
C601 2401-002300 C-AL 47?F,20%,50V,GP,TP,6.3x11,5mm 1 SNA
C105 2401-003036 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm 1 SNA
BZ61 3002-001129 BUZZER-PIEZO 85DB,-,-,2KHZ,- 1 SNA
RY72 3501-001154 RELAY-MINIATURE 12Vdc,200mW,3000mA,1FormA,10mS,
10mS
1 SA
RY73 3501-001154 RELAY-MINIATURE 12Vdc,200mW,3000mA,1FormA,10mS,
10mS
1 SA
RY74 3501-001154 RELAY-MINIATURE 12Vdc,200mW,3000mA,1FormA,10mS,
10mS
1 SA
RY71
3501-001268 RELAY-POWER 12V,0.9W,25000mA,SPST,20mS,10mS 1 SA
SS71 3502-000115 SSR 12Vdc,-,2A,1mS,1mS 1 SNA
F701 3601-000263 FUSE-CARTRIDGE 250V,3.15A,TIME-LAG,GLASS,5x20mm 1 SNA
F702 3601-001209 FUSE-RADIAL LEAD 250V,1A,TIME-LAG,-,8.5x8mm 1 SNA
CN72 3711-000262 HEADER-BOARD TO
CABLE
1WALL,3P,1R,7.92MM,STRAIGHT,SN,
WHT
1 SNA
