Samsung Electronics
10. PCB Diagram
The red number connecter is not used.
3
2
10-1
1
4
5
Motor RPM Feedback
Temperature Sensor
BLADE-H Step Motor
MAIN PBA CONNECTOR
Indoor Fan Motor
1
2
3
5
4
