Samsung AQ09NSA User Manual

2-2 Samsung Electronics
2-2 Product Specifications
MODEL
ITEM
AQ09NSA AQ09NSB
INDOOR UNIT OUTDOOR UNIT INDOOR UNIT
OUTDOOR
UNIT
type WALL MOUNTED WALL MOUNTED
perfor-
mance
Cooling/Heating(ISO)
KW
2.75/2.9 2.75/2.9
BTU/h
- -
cooling/heating(SASO)
kcal - -
Dehumidifying
l/h - -
Air volume Cooling
m3/nin(H/
M/L)
8.5/6.7/4.8 17 8.5/6.7/4.8 17
Noise Cooling Db(H/L) 40 55 40 55
EER
Cooling/
Heating(ISO)
W/W 2.8/3.2 3.2/3.4
Cooling/
Heating(SASO)
Btu/w.h
- -
Power ph-v-HZ
220-240/50 220-240/50
power
Power consumption
Cooling/
Heating(ISO)
W 980/900 855/850
Cooling/
Heating(SASO)
W - -
OPERATING CURRENT
Cooling/
Heating(ISO)
A 4.4/4.1 4.4/4.1
Cooling/
Heating(SASO)
- -
Power Factor Cooling
% 96.8/95.4 84.4/90.1
Starting current
A 21 21
Power CORD
LENGTH m 5.5 5.5
HUMBER OF
COREWIRRE
5 5
CAPACITY
A 25 25
Size
OUTER DIMENSION
W*H*D
mm 825*285*189 660*475*242 825*285*189 660*475*242
inch - - - -
Refrigerant
unquid mm*l(m) 6.35*5 6.35*5
Gas
mm*l(m) 9.52*5 9.52*5
Drain Hose
d*l(m) 18*2 18*2
COMPRESSOR
TYPE Roto G4A097JUAEP Roto G4A097JUAEP
MOTER
TYPE INDUCTION MOTOR(PSC) INDUCTION MOTOR(PSC)
TATED OUTPUT
9700 9700
oil TYPE POE(FREONa68ES-T) POE(FREONa68ES-T)
BLOWER
TYPE CROSS FLOW
PROPELLER CROSS FLOW PROPELLER
MOTER
TYPE
RESIN/STEEL STEEL RESIN/STEEL STEEL
TATED OUTPUT
w 37 58 37 58
Heat exchange 2ROW 10STEP
1ROW20STEP 2ROW 10STEP 1ROW20STEP
Refrigeraant Control unit Capillary Tube Capillary Tube
Freezer oil Capicity cc
280 280
Refrigeraant changeer
g R410A 525 R410A 525
prodtection Device(olp) NILET NILET
cooling Test Condition
DB27,WB19 DB35,WB24 DB27,WB19 DB35,WB24
Maximum opertation Condition
DB32,WB23 DB43,WB26 DB32,WB23 DB43,WB26

Samsung AQ09NSA Specifications

General

Brand	Samsung
Model	AQ09NSA
Category	Air Conditioner
Language	English
