Samsung Electronics 14-8
14-5-1 Cleaning Your Air Conditioner
For the best use of your air conditioner, you must clean it every 2 weeks regularly to remove the dust that accumulates on the air filter.
14-5 Cleaning/Filter Change
1. Slide the lower front grille down.
2. Slide the upper front grille up slightly, then open the grille by pulling right
and left sides of the grille.
3. Disassemble the upper front grille by opening the grille completely.
4. Lift out the bottom edge of the air filters and pull down to release them.
5. Remove all dust on the air filters with a vacuum cleaner or brush.
6. When you have finished, insert the top part of the filters into their slot
and push down on the bottom edge until they click into place.
7. Clean the front grille with a damp cloth and mild detergent
(do NOT use benzene, solvents or other chemicals).
8. Fix the left side of grille support, then insert the right side of grille support.
Note :
• If you have not used the air conditioner for a long period of time, set the fan
going for three to four hours to dry the inside of the air conditioner thoroughly.
• To close the upper front grille completely after cleaning filters, turn on and turn off the air conditioner.
• Before cleaning your air conditioner, ensure that you have switched off the breaker used for the unit.
1
Front grille
Air filter
Body groove
Body
Front grille
Hook
Body
To Next Page
