26
There are two refrigerant pipes of dierent diameters :
◆
A smaller one for the liquid refrigerant
◆
A larger one for the gas refrigerant
◆
The inside of copper pipe must be clean & has no dust
1. Remove the pinch pipe on the pipes and connect the assembly pipes to each pipe, tightening the nuts, rst manually
and then with a torque wrench, a spanner applying the following torque.
2. Must use insulator which is thick enough to cover the refrigerant tube to protect the condensate water on the outside
of pipe falling onto the oor and the eciency of the unit will be better.
3. Cut o any excess foam insulation.
4. Be sure that there must be no crack or wave on the bended area.
5. It would be necessary to double the insulation thickness[0.4inch(10mm) or more] to prevent condensation even on the
insulator when if the installed area is warm and humid.
6. Do not use joints or extensions for the pipes that connect the indoor and outdoor unit. The only permitted connections
are those for which the units are designed.
t *GUIFQJQFTNVTUCFTIPSUFOFESFGFSUPQBHF
Refrigerant oil
Spanner
Union
Torque wrench
Flare nut
Connecting the refrigerant pipe
Drain hose connection port
Liquid refrigerant port
Gas refrigerant
port
MA Duct Type
Outer Diameter(D)
Torque
</tNMCGrGU>
NNw
NNw
NNw
NNw
NNw
