66 _ Exploded views and Parts list
5-9. PARTS LIST (SA/SC OTHER)
MODEL CODE: DV231AEW/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Code No. Description Specication Install. Point QTY Un SA/SNA
6002-000213 SCREW-TAPPING TH,+,-
,1,M4,L12,ZPC(WHT),SWRCH18A,-
D.CON+DUCT-OUTLET 1 PC SA
6002-000213 SCREW-TAPPING TH,+,-
,1,M4,L12,ZPC(WHT),SWRCH18A,-
D/FRONT+DUCT-
OUTLET
2 PC SA
6002-000213 SCREW-TAPPING TH,+,-
,1,M4,L12,ZPC(WHT),SWRCH18A,-
BOTTOM+BRKT-
MOTOR
3 PC SA
6002-000215 SCREW-TAPPING TH,+,NO,1,M4,L16,ZPC(WHT),SW
RCH18A
ASSY DRUM
WRAPPER
12 PC SA
6002-000239 SCREW-TAPPING TH,+,NO,2S,M4,L8,ZPC(WHT),SW
RCH18A
BOTTOM+BRK-LEG 4 PC SA
6002-000239 SCREW-TAPPING TH,+,NO,2S,M4,L8,ZPC(WHT),SW
RCH18A
C/BACK+EXHAUST 1 PC SA
6002-000239 SCREW-TAPPING TH,+,NO,2S,M4,L8,ZPC(WHT),SW
RCH18A
FRAME+COVER-BACK 3 PC SA
6002-000239 SCREW-TAPPING TH,+,NO,2S,M4,L8,ZPC(WHT),SW
RCH18A
D/BACK+BRKT-D/B(S) 4 PC SA
6002-000239 SCREW-TAPPING TH,+,NO,2S,M4,L8,ZPC(WHT),SW
RCH18A
D/BACK+BRKT-D/B(T) 2 PC SA
6002-000239 SCREW-TAPPING TH,+,NO,2S,M4,L8,ZPC(WHT),SW
RCH18A
D/BACK+DUCT-AIR 3 PC SA
6002-000239 SCREW-TAPPING TH,+,NO,2S,M4,L8,ZPC(WHT),SW
RCH18A
HOLDER-PCB+M.PCB 1 PC SA
6002-000470 SCREW-TAPPING TH,+,NO,1,M4,L10,ZPC(WHT),SW
RCH18A
D/CONNEC.+C/DUCT 2 PC SA
6002-000470 SCREW-TAPPING TH,+,NO,1,M4,L10,ZPC(WHT),SW
RCH18A
THERMISTOR+G/DUCT 2 PC SA
6002-000470 SCREW-TAPPING TH,+,NO,1,M4,L10,ZPC(WHT),SW
RCH18A
THERMOSTAT+G/
DUCT
2 PC SA
6002-000470 SCREW-TAPPING TH,+,NO,1,M4,L10,ZPC(WHT),SW
RCH18A
G/FAN+C/DUCT 1 PC SA
6009-001317 SCREW-SPECIAL CH,+,-,M4,L10,ZPC(WHT),SWRCH1
8A,FP,TAPTITE
ASSY FRAME CASE 2 PC SA
6009-001476 SCREW-HEX HEX,+,M5,L10,ZPC(WHT),SWRCH
18A,2
COVER-TOP+B/C/TOP 2 PC SA
DC63-10001C ABSORBER
SPONGE
EPDM,
T3.0,W15,L350,BLK,OJC3000
ASSY FRAME
PLATE(U)
1 PC SA
DC69-00367L SHEET-PE HELIOS,PE-FOAM,T2,W800,L800 COVER-TOP 1 PC SA
DC97-15847A ASSY SCREW ACE-PJT,
DV419AEU,SWRCH18A,M4*L12
F/FRONT+D/FRONT 2 PC SA
