68 _ Exploded views and Parts list

5-10. PARTS LIST (SCREW TYPE)

MODEL CODE: DV231AEW/XAA

Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)

Code No. Description Speciﬁcation QTY Un SA/SNA

6001-001668 SCREW-MACHINE TH,+,M5,L16,PASS,STS430,FP,NYLOCK 1 PC SA

6001-001773 SCREW-MACHINE TH,+,-,M5,L12,PASS,STS430,-,SEAL-LOCK 4 PC SA

6002-000213 SCREW-TAPPING TH,+,-,1,M4,L12,ZPC(WHT),SWRCH18A,- 6 PC SA

6002-000215 SCREW-TAPPING TH,+,NO,1,M4,L16,ZPC(WHT),SWRCH18A 12 PC SA

6002-000231 SCREW-TAPPING TH,+,NO,2S,M4,L12,ZPC(WHT),SWRCH18A 11 PC SNA

6002-000234 SCREW-TAPPING TH,+,NO,2S,M4,L16,ZPC(WHT),SWRCH18A 12 PC SNA

6002-000239 SCREW-TAPPING TH,+,NO,2S,M4,L8,ZPC(WHT),SWRCH18A 30 PC SA

6002-000241 SCREW-TAPPING TH,+,-,2S,M5,L12,ZPC(WHT),SWRCH18A,- 1 PC SNA

6002-000445 SCREW-TAPPING TH,+,2,M4,L18,PASS,STS304 4 PC SNA

6002-000470 SCREW-TAPPING TH,+,NO,1,M4,L10,ZPC(WHT),SWRCH18A 7 PC SA

6002-000488 SCREW-TAPPING PH,+,NO,2S,M3,L16,ZPC(WHT),SWRCH18A 1 PC SA

6002-001149 SCREW-TAPPING TH,+,NO,2S,M4,L12,NI PLT,SWRCH18A 17 PC SNA

6002-001306 SCREW-TAPPING TH,+,-,1,M4,L14,ZPC(WHT),SWRCH18A,- 17 PC SNA

6002-001320 SCREW-TAPPING TH,+,NO,2S,M4,L8,PASS,STS304 2 PC SNA

6002-001384 SCREW-TAPPING TH,+,WT,C-TITE,M4,L10,ZPC(WHT),SWRCH18A,GREE

N PAINT

1 PC SNA

6003-001768

SCREW-TAPTYPE

TH,+,WT,S,M4,L10,ZPC(WHT),SWRCH18A

1 PC SNA

6006-001174 SCREW-TAPPING TH,+,WE,2S,M4,L12,ZPC(WHT),SWRCH18A 13 PC SNA

6009-001317 SCREW-SPECIAL CH,+,-,M4,L10,ZPC(WHT),SWRCH18A,FP,TAPTITE 2 PC SA

6009-001342 SCREW-SPECIAL TH,+,-,M5,L11,ZPC(WHT),SWRCH18A,MACHINE,2BODY 1 PC SA

6009-001476 SCREW-HEX HEX,+,M5,L10,ZPC(WHT),SWRCH18A,2 2 PC SA

DC97-15847A ASSY SCREW ACE-PJT,DV419AEU,SWRCH18A,M4*L12 2 PC SA
